Moore Industries SPA2 - Page 21

www.miinet.comMoore Industries-International, Inc.
- 21 -
User’s Manual
224-790-00K
May 2018
Figure 3.4. SPA
2
Dimensions
Table 3.3. SPA
2
(TPRG) Input Hook Connections
+
–
143 2 143 2 143 2
Thermocouple
and Millivolt
Input
2-Wire RTD
or Decade
Resistance Box
143
2
3-Wire RTD
or Decade
Resistance Box
4-Wire RTD
or Decade
Resistance Box
143 2
Potentiometer
Input
14 3 2
Dual 2-Wire Sensor
Measurement 1
Measurement 2
One 2-Wire Sensor and One 3-Wire Sensor
Measurement 1
Measurement 2
Three 2-Wire Sensors
Measurement 1
Measurement 2
14 3 2
14 3 2
Measurement 3
144mm
(5.7 in)
56mm
(2.2 in)
102mm
(4.0 in)
Programmable Limit Alarm Trips
SPA
2
SECTION 3
