SECTION 4
Band Alarm Configuration
Figure 4.17 gives an overview of the Band Alarm configuration menu.
Band Alarms are used if the user desires an alarm condition if a process value outside of a defined
range (lower and upper trip point).
1. At the “CONFG ALARM” menu, press SELECT. Use the UP and DOWN buttons to toggle
between the four alarms. When the desired alarm appears, press SELECT.
2. At the “ALARM TYPE” menu, press SELECT. From here you will choose your alarm type.
Use the UP and DOWN buttons to scroll through the selections. Press SELECT once
“ALARM BAND” is displayed.
3. At “ENTER TRIP 1 (TPRG)” or “ENTER LOWER (HLPRG) (Smart Ranging)” press SELECT
and use the UP and DOWN buttons to set your ENTER TRIP 1 or ENTER LOWER value, then
press SELECT. You also choose to use the DOWN button instead to select “INPUT TRIP 1
(TPRG) or INPUT LOWER (Standard Ranging)” then use the UP and DOWN buttons to select
your INPUT TRIP 1 or INPUT LOWER value.
4. At “ENTER TRIP 2 (TPRG)” or “ENTER UPPER (HLPRG) (Smart Ranging)” press SELECT
and use the UP and DOWN buttons to set your ENTER TRIP 2 or ENTER UPPER value, then
press SELECT. You also choose to use the DOWN button instead to select “INPUT TRIP 2
(TPRG) or INPUT UPPER (Standard Ranging)” then use the UP and DOWN buttons to select
your INPUT TRIP 2 or INPUT UPPER value.
5. Press SELECT at “ENTER DBAND” and enter your dead band value if using dead band.
Press SELECT once your desired setting appears.
Dead Band– The Dead Band is the range within which an alarm relay remains in an alarm
condition even after the monitored process variable input has returned to a safe level, at or
below/above the trip point setting.
6. Press SELECT at “ENTER DELAY” and input your desired delay time by using the UP and
DOWN buttons.
Delay– When your unit is in an alarm condition, the delay is the amount of time you set
(0-120sec) to elapse before a relay trip.
7. At the “SET LATCH” display, press SELECT and choose “LATCH ON” using the UP and
DOWN buttons; press SELECT.
Refer to the “Trip Alarm Configuration” section for a description of latching alarms.
8. Press SELECT at “SET FSAFE” to enter the menu. Then use the UP and DOWN buttons to
switch from “ALARM FSAFE” to “ALARM NONFS”. Make your selection and press SELECT.
Refer to the “Trip Alarm Configuration” section for a description of fail safe and non fail safe
alarms.
9. “SENSOR/INPUT FAULT” appears. Select whether or not to enable the sensor or input failure
alarm by using the UP and DOWN buttons; press SELECT.
Refer to the “Trip Alarm Configuration” section for a description of fail safe and non fail safe
alarms.
10. If you are to program other alarms, use the UP and DOWN buttons to reach your next alarm
and follow the steps described in the appropriate alarm configuration section.
If you have completed your alarm configurations, use the UP and DOWN buttons to bypass
the alarm menu. To exit, press SELECT at the “ALARM EXIT” display.
