Programmable Limit Alarm Trips
SPA
2
SECTION 4
Stuck Input Alarm Configuration
Figure 4.18. gives an overview of the Stuck Input Alarm configuration menu.
If you wish to be notified when an input appears to be ‘stuck’ use the Stuck Input Alarm. The alarm
will be set if the input does not change by the defined amount over a set time period.
1. At the “CONFG ALARM” menu, press SELECT. Use the UP and DOWN buttons to toggle
between the alarms. When the desired alarm appears, press SELECT.
2. At the “ALARM TYPE” menu, press SELECT. From here you will choose your alarm type.
Use the UP and DOWN buttons to scroll through the selections. Press SELECT once
“ALARM STUCK” is displayed.
3. At “ENTER DELTA” press SELECT and use the UP and DOWN buttons to set your delta
value. Press SELECT.
DELTA– This is the amount by which the process variable must change.
4. At the “ENTER TIME” menu, press SELECT. Using the UP and DOWN buttons, set the time
and press SELECT.
TIME– The span (1-300sec) in which the delta must change before the alarm is set.
Note: To set the correct value for DELTA and TIME, you need to understand the expected process
variations to avoid false trips and the input signal noise and averaging filter settings to prevent
missing stuck inputs.
Note: When configuring a Stuck Input alarm, “LATCH ON” must be selected in the “SET LATCH’”
menu.
6. At the “SET LATCH” display, press SELECT and choose “LATCH ON” using the UP and
DOWN buttons; press SELECT.
Refer to the “Trip Alarm Configuration” section for a description of latching alarms.
7. Press SELECT at “SET FSAFE” to enter the menu. Then use the UP and DOWN buttons to
switch from “ALARM FSAFE” to “ALARM NONFS”. Make your selection and press SELECT.
Refer to the “Trip Alarm Configuration” section for a description of fail safe and non fail safe
alarms.
8. “SENSR/INPUT FAULT” appears. Select whether or not to enable the input failure alarm by
using the UP and DOWN buttons; press SELECT.
9. “RANGE ALARM” appears. Select whether or not to enable the range alarm by using the UP
and DOWN buttons; press SELECT. If enabled “LOWER POINT” appears, then use the UP
and DOWN buttons to set your lower point value, press SELECT. “UPPER POINT” appears,
then use the UP and DOWN buttons to set your upper point value, press SELECT. “EXIT
RANGE” appears. Press SELECT. “EXIT ALRM*” appears. If range alarm not enabled “EXIT
ALRM*” appears.
Note: When setting the Range Alarm, the values in Lower Point must be greater than those of the
Sensor Lower Limit, and less than those set in Lower Range. When setting the Upper Point, the
value must be less than the Sensor Upper Limit, and greater than those set in Upper Range.
10. If you are to program other alarms, use the UP and DOWN buttons to reach your next alarm
and follow the steps described in the appropriate alarm configuration section.
If you have completed your alarm configurations, use the UP and DOWN buttons to bypass
the alarm menu. To exit, press SELECT at the “ALARM EXIT” display.
