Pre Start Inspection and Operation
3.21
Removal of Attachment
1. Lower the attachment onto a rm, level surface.
2. Shut o the machine engine.
3. Rotate the attachment lock pins to the UNLOCKED position (Item 1, Figure 3–27).
Figure 3-27 Attachment Locks in Unlocked Position
4. Start the engine and rotate the mounting plate downwards.
5. Back away from the attachment.
It may be necessary to lower the loader arm assembly slightly to fully disengage from
the attachment.
NOTICE
1
1
Pins Unlocked
