Routine Service and Maintenance
4.11
Weekly Maintenance Procedures
Do the following procedures weekly or every 50 operating hours:
1. Do all Daily maintenance procedures.
2. Check the battery (Item 6, Figure 4–12) and cable connections (Items 4 and 5, Figure
4–12) for signs of leaking, corrosion or damage. To complete this check, remove the
service access panel (Item 1, Figure 4–12) by removing the four bolts and washers (Items
2 and 3, Figure 4–12) and then the access panel.
Make sure that the battery clamp (Item 7, Figure 4–12) is securely holding the battery in
position.
Figure 4-12 Battery and Cable Connections
NOTICE
1
2
3
4
5
6
7
