Morbark BOXER 320 - Section 6 - General Specifications

6.1
Section 6 - General Specications
Engine System
Type
Kohler Command Pro
Cooling System
Air Cooled
HP / KW
20 / 14.9
Fuel Tank
4.5 Gallons
Hydraulic System
Pressure (Auxiliary/Boom & Tilt Cylinder Circuit)
3000 psi system relief
Pressure Ground Drive Circuit
3000 psi system relief
Flow Auxiliary
8 GPM (High) 3 GPM (Low) @ 3700 rpm
Flow Ground Drive
8 GPM (High) 3 GPM (Low) @ 3700 rpm
Reservoir Capacity
16 gallons
Filter
10 Micron
Electrical System
Battery
12 Volt
Control System
Starting
Keyed ignition switch
Throttle/Choke
Remote Mount Throttle - Choke engine mounted
Steering
Two spring centered control lever with zero turning
type controls
Boom/Loader Arms
Three position, spring centered lever control. Up,
neutral, and down
Bucket/Attachment Tilt
Three position, spring centered lever control. Extend,
neutral, and curl
Auxiliary/Attachment Control
Two position, detented, Third position spring return
to neutral
Wheel/Track Options
7” Wide Track
Drive Train
Two Wheel Motors
Creep Control
N/A
Operator Platform
Suspended Stand On Platform
Mount Plate
Universal CUL Attachment Plate
Warranty
Engine Warranty
Two Year
Product Warranty
One Year
Ground Drive System-Dimensions
Units English Metric
Wheelbase 32 in. 813 mm
Ground Clearance 5.0 in. 127 mm
Overall Length (w/ Bucket) 87 in. 2210 mm
Overall Length (without Bucket) 68 in. 1727 mm
Overall Width (Fully Retracted) N/A in. N/A mm
Overall Width (Fully Extended) 34.5 in. 876 mm
Overall Height 49 in. 1235 mm
Overall Operating Height (Fully Raised) 92 in. 2337 mm
