Morita Veraview iX User Manual

38
Operation 2018-10-22
Guidance and Manufacturer’s Declaration – Electromagnetic Immunity
This device is intended for use in the electromagnetic environment specied below.
The customer or the user of this device should assure that it is used in such an environment.
Immunity Test IEC 60601 Test Level Compliance Level
Electromagnetic Environment
– Guidance
Electrostatic
discharge (ESD)
IEC 61000-4-2
±8 kV contact
±2 kV, ±4 kV, ±8 kV, ±15 kV air
±2 kV, ±4 kV, ±6 kV, ±8 kV
contact
±2 kV, ±4 kV, ±8 kV, ±15 kV air
Floors should be wood, concrete
or ceramic tile. If oors are covered
with synthetic material, the relative
humidity should be at least 30%.
Electrical fast
transients/bursts
IEC 61000-4-4
±2 kV for power supply lines
±1 kV for input/output lines
±2 kV for power supply lines
±1 kV for input/output lines
Mains power quality should be that
of a typical commercial or hospital
environment.
Surge
IEC 61000-4-5
AC/DC power
±0.5 kV, ±1 kV line(s) to line(s)
±0.5 kV, ±1 kV, ±2 kV line(s) to
earth
Signal input/output
±2 kV line(s) to earth
AC/DC power
±0.5 kV, ±1 kV line(s) to line(s)
±0.5 kV, ±1 kV, ±2 kV line(s) to
earth
Signal input/output
*1
±2 kV line(s) to earth
Mains power quality should be that
of a typical commercial or hospital
environment.
Voltage dips, short
interruptions and
voltage variations on
power supply lines
IEC 61000-4-11
dips
0%
U
T
: 0.5 cycle (at 0, 45, 90,
135, 180, 225, 270, 315°)
0%
U
T
: 1 cycle (at 0°)
70%
U
T
: 25/30 cycles (at 0°)
25 (50 Hz)/30 (60 Hz)
short interruptions
0%
U
T
: 250/300 cycles
250 (50 Hz)/300 (60 Hz)
dips
0%
U
T
: 0.5 cycle (at 0, 45, 90,
135, 180, 225, 270, 315°)
0%
U
T
: 1 cycle (at 0°)
70%
U
T
: 25/30 cycles (at 0°)
25 (50 Hz)/30 (60 Hz)
short interruptions
0%
U
T
: 250/300 cycles
250 (50 Hz)/300 (60 Hz)
Mains power quality should be that
of a typical commercial or hospital
environment.
If user of this device requires
continued operation during
power mains interruptions, it is
recommended that this device be
powered from an uninterruptible
power supply or a battery.
Power frequency
(50/60 Hz)
magnetic eld
IEC 61000-4-8
30 A/m (r.m.s.)
50 Hz or 60 Hz
30 A/m (r.m.s.)
50 Hz or 60 Hz
Power frequency magnetic eld
should be at levels characteristic
of a typical location in a typical
commercial or hospital environment.
NOTE 1:
U
T
is the a.c. mains voltage prior to application of the test level.
NOTE 2: r.m.s.: root mean square
*1: Not applicable because it does not connect directly to outdoor cable.
