ATTACHING THE WHEELS / INVERTING THE WHEELS
Attaching the Wheels
This trolley does not have a specic left and right wheel. To attach the rear wheels, follow these simple steps:
1. Push and hold the quick release button in towards the centre of the wheel
2. Slide the wheel onto the trolley axle as far as it will go (onto the inner groove)
3. Once in position, release the button and pull the wheel outwards slightly to lock
4. An audible ‘click’ will conrm the wheel is in the correct position
To check you have attached the wheels correctly onto the inner groove, you will nd they will not rotate freely in either direction.
The outer groove can be used as a “free-wheel” option if you run out of battery power. Simply slide the wheel onto the outer groove
and pull the wheel outwards slightly to lock. Once connected, the wheel will spin freely without resistance in both directions.
Inverting the Wheels
The rear wheels can be inverted to reduce the trolley width for transportation and storage.
1. Push and hold the quick release button while sliding the wheel off the axle
2. Flip the wheel over, push and hold the button, then slide onto the axle
3. Release the button and pull the wheel out slightly until it engages with the free wheel groove
It is important the wheels are not pushed on too far. They should not touch the battery tray.
