Motorola ASTRO SPECTRA - ASTRO Digital Spectra Models W4, W5, W7, and W9

6881076C20-E February 3, 2003
Encryption: Over-the-Air Rekeying 7-9
7.6.2 ASTRO Digital Spectra Models W4, W5, W7, and W9
1. To enter the Advanced
Secure menu, press
and hold the
 button
until a tone sounds.
2. Do one of the following;
Model W4: Using the Mode knob, scroll to the
REKY option.
OR
Models W5, W7, or W9: Using the Mode rocker switch, scroll
to the
REKY REQ option.
3. To enter the rekey request menu, press and release the
SEL
button.
4. To initiate a rekey request, press and release either the Sel
button or the PTT button.
The radio displays
PLS WAIT (W4, W5, W7) or PLEASE WAIT
(W9).
XMIT
BUSY
Mode
Volume
Pwr
Phon
Call SelScan
Mic
Home
Dim
H/L
Dir Mon
SECURE
INDICATOR
MODE
KNOB
HOME SECURE
Model W4
Mode
Vol
Mic
Phon
Call Sel
H/L Mon Dir
PWR
Scan
XMIT
BUSY
DIM
HOME
MAEPF A
MODE
HOME
SECURE
INDICATOR
SECURE
Model W5
O #Del Rcl
Mode
Vol
Mic
Phon
Call Sel
PWR
Scan
XMIT
BUSY
DIM
HOME
1 Ste 2
3
Lck
4 Sts
5 Rpg
6 Msg
7 H/L
8 Mon
9 Dir
MODE
HOME
SECURE
INDICATOR
SECURE
Model W7
Model W9
XMIT BUSY
123
456
789
0
DIM
Pri
Non
Pri
Emer Dir
Scan
Call
Mode Vol Sel
Home
Page Rpgm
Site
Phon H/L Lock
Rcl Sql
Del
MODE SELECT
HOME
Sts Msg
Srch
SECURENET
SECURE
