Motorola ASTRO SPECTRA Service Manual

January 29, 2003 6881076C20-E
xxiv Model Numbering, Charts, and Specifications
ASTRO Digital Spectra UHF 20–40 Watt Model Chart (cont.)
Model Number Description
D04QKH9PW3AN Model W3 (403-433 MHz), 20-40 Watt, 128 Channels
D04QKF9PW4AN Model W4 (403-433 MHz), 20-40 Watt, 128 Channels
D04QKF9PW5AN Model W5 (403-433 MHz), 20-40 Watt, 128 Channels
D04QKH9PW7AN Model W7 (403-433 MHz), 20-40 Watt, 255 Channels
T04QKH9PW9AN Model W9 (403-433 MHz), 20-40 Watt, 255 Channels
D04RKH9PW3ANSP01 Model W3 (450-482 MHz), 20-40 Watt, 128 Channels
D04RKF9PW4AN Model W4 (450-482 MHz), 20-40 Watt, 128 Channels
D04RKF9PW5AN Model W5 (450-482 MHz), 20-40 Watt, 128 Channels
D04RKH9PW7AN Model W7 (450-482 MHz), 20-40 Watt, 255 Channels
T04RKH9PW9AN Model W9 (450-482 MHz), 20-40 Watt, 255 Channels
D04SKH9PW3AN Model W3 (482-512 MHz), 20-40 Watt, 128 Channels
D04SKF9PW4AN Model W4 (482-512 MHz), 20-40 Watt, 128 Channels
D04SKF9PW5AN Model W5 (482-512 MHz), 20-40 Watt, 128 Channels
D04SKH9PW7AN Model W7 (482-512 MHz), 20-40 Watt, 255 Channels
T04SKH9PW9AN Model W9 (482-512 MHz), 20-40 Watt, 255 Channels
Item No. Description
XXXXX HAE4003_ Antenna, Quarterwave
XXXX HLE6000_ VCO Carrier, Range 3
XXXX HLE6043_ Power Amplifier, 40W, Range 3
XXXX HLE6103_ VCO Hybrid Kit, Range 3
XXXX HRE6003_ Receiver F/E, Range 3
XX
XXXXXXXXXXXXX HSN4018_ Speaker
X X X HCN1078_ W9 Control Head
X XXXX HAE4004_ Antenna, Roof Top
X XXXX HLE6041_ VCO Carrier, Range 4
X XXXX HLE6044_ Power Amplifier, 40W, Range 4
X XXXX HLE6104_ VCO Hybrid Kit, Range 4
X XXXX HRE6004_ Receiver F/E, Range 4
X
X X HLN6459_ W3 Interface Board
X
X X HMN4044_ ASTRO Handheld Control Head (W3)
X = Item Included
_ = the latest version kit. When ordering a kit, refer to your specific kit for the suffix number.
* = kit not available. Order piece parts from the Customer Care and Services Division.

Motorola ASTRO SPECTRA Specifications

General

Frequency Range	136-174 MHz, 403-470 MHz
Number of Channels	Up to 255
Channel Spacing	12.5 kHz, 20 kHz, 25 kHz
Modulation	FM
Operating Temperature	-22°F to +140°F (-30°C to +60°C)
