February 3, 2003 6881076C20-E
4-2 Test Equipment, Service Aids, and Tools: Service Aids and Recommended Tools
Table 4-2 contains a listing of the plug-in elements that are available for the BIRD wattmeters listed in
the
Table 4-1.
Table 4-3 contains a listing of non-Motorola test equipment recommended for servicing mobile
radios.
4.2 Service Aids and Recommended Tools
Refer to the tables in this section for a listing and description of the service aids and tools designed
specifically for servicing this family of radios, as well as the more common tools required to
disassemble and properly maintain the radio. These kits and/or parts are available from the Motorola
Parts Division offices listed in the Replacement Parts Ordering section located on page A-1of this
manual.
Table 4-4 lists recommended service aids common to both ASTRO Digital Spectra and ASTRO
Digital Spectra Plus radios. While all of these items are available from Motorola, most are standard
shop equipment items, and any equivalent item capable of the same performance can be substituted
for the item listed.
Table 4-2. Wattmeter Plug-In Elements
Power 25-60MHz 50-125MHz 100-250MHz 200-500MHz 400-1000MHz
5W --- 01-80305F21 01-80305F29 01-80305F38 01-80305F46
10W --- 01-80305F22 01-80305F30 01-80305F39 01-80305F47
25W 01-80305F15 01-80305F23 01-80305F31 01-80305F40 01-80305F48
50W 01-80305F16 01-80305F24 01-80305F32 01-80305F41 01-80305F49
100W 01-80305F17 01-80305F25 01-80305F33 01-80305F42 01-80305F50
250W 01-80305F18 01-80305F26 01-80305F34 01-80305F43 01-80305F51
500W 01-80305F19 01-80305F27 01-80305F35 01-80305F44 01-80305F52
1000W 01-80305F20 01-80305F28 01-80305F36 01-80305F45 01-80305F53
Table 4-3. Recommended Non-Motorola Test Equipment
Model Number Description Application
Agilent 8901_ Modulation Analyzer Reference oscillator deviation and compensation
measurements
Weinschel 49 30 43 30 dB RF Attenuator For tests that require a modulation analyzer or
wattmeter
