Motorola ASTRO SPECTRA Service Manual

January 29, 2003 6881076C20-E
xx Model Numbering, Charts, and Specifications
ASTRO Digital Spectra VHF 25–50 and 50–110 Watt Model Chart
Model Number Description
D04JKH9PW3AN Model W3 (136-145.9 MHz), 25-50 Watt, 128 Channels
D04JKF9PW4AN Model W4 (136-162 MHz), 25-50 Watt, 128 Channels
D04JKF9PW5AN Model W5 (136-162 MHz); 25-50 Watt, 128 Channels
D04JKH9PW7AN Model W7 (136-162 MHz), 25-50 Watt, 255 Channels
T04JKH9PW9AN Model W9 (136-162 MHz), 25-50 Watt, 255 Channels
D04KKF9PW3AN Model W3 (146-174 MHz), 25-50 Watt, 128 Channels
D04KKF9PW4AN Model W4 (146-174 MHz), 25-50 Watt, 128 Channels
D04KKF9PW5AN Model W5 (146-174 MHz), 25-50 Watt, 128 Channels
D04KKH9PW7AN Model W7 (146-174 MHz), 25-50 Watt, 255 Channels
T04KKH9PW9AN Model W9 (146-174 MHz), 25-50 Watt, 255 Channels
T04JLH9PW3AN Model W3 (136-145.9 MHz), 50-110 Watt, 128 Channels
T04JLF9PW4AN Model W4 (136-162 MHz), 50-110 Watt, 128 Channels
T04JLF9PW5AN Model W5 (136-162 MHz), 50-110 Watt, 128 Channels
T04JLH9PW7AN Model W7 (136-162 MHz), 50-110 Watt, 255 Channels
T04JLH9PW9AN Model W9 (136-162 MHz), 50-110 Watt, 255 Channels
T04KLH9PW3AN Model W3 (146-174 MHz), 50-110 Watt, 255 Channels
T04KLF9PW4AN Model W4 (146-174 MHz), 50-110 Watt, 128 Channels
T04KLF9PW5AN Model W5 (146-174 MHz), 50-110 Watt, 128 Channels
T04KLH9PW7AN Model W7 (146-174 MHz), 50-110 Watt, 255 Channels
T04KLH9PW9AN Model W9 (146-174 MHz), 50-110 Watt, 255 Channels
Item No. Description
XXXXX X XXXX HRD6001_ Front-End Rcvr Board Kit (Range 1, 136-162 MHz)
XXXXX XXX X X HRD6002_ Front-End Rcvr Board Kit (Range 2, 146-174 MHz)
XX
XXXXXXXXXXXXXXXX X X HRN6014_ RF Board Kit
XX
XXXXXXXXXXXXXXXXXXHLD4342_ VCO Board Kit
XX
XXX X XXXX HLD6061_ VCO Hybrid Kit (Range 1, 136-162 MHz)
XXXXX XXXXXHLD6062_ VCO Hybrid Kit (Range 2, 146-174 MHz)
XX
XXXXXXXXXXXXXXXXXXHLN5558_ Command Board Kit
XX
XXXXXXXXXXXXXXXXXXHLN6458_ VOCON Board Kit
X XXXX HLD6064_ Power Amplifier Board
(50-110W, Range 1, 136-162 MHz)
XX
XXXXXXXX HLD6022_ Power Amplifier Board
(25-50W, Range 1, 136-174 MHz)
XXXXXHLD6063_ Power Amplifier Board
(50-110W, Range 2, 146-174 MHz)
X X HLN6344_ Interface Board
X
XX XXX HLN6401_ Control Head Interconnect Board
X
X X X AAHN4045_ W4 Control Head
XXXXXXXXHLN6486_ High-Power Interconnect Board
XXX X X X HLN6432_ Control Head Back Housing
XX X X XX X X HLN6396_ W5,W7 Control Head Board
X X X X HCN1078_ W9 Control Head
X
XX XXX XXX X X X HMN1080_ Microphone
X X X X HMN1061_ Microphone
XX
XXXXXXXX HSN4018_ Speaker
X XXXXXXXXXHSN6001_ Speaker
X X X X HLN4921_ Control Head (W9) Trunnion
X X HLN5488_ Radio Microphone Installation Hardware (W9 Trunnion)
X
X X X HLN6185_* Remote-Mount, SECURENET Control-Head Hardware
XXX X X X HLN6231_ Remote W4, W5, W7 Control-Head Trunnion
X XXXXXXXXXHLN6233_* Option Connector Hardware
X = Item Included
_ = the latest version kit. When ordering a kit, refer to your specific kit for the suffix number.
* = kit not available. Order piece parts from the Customer Care and Services Division.

Motorola ASTRO SPECTRA Specifications

General

Frequency Range	136-174 MHz, 403-470 MHz
Number of Channels	Up to 255
Channel Spacing	12.5 kHz, 20 kHz, 25 kHz
Modulation	FM
Operating Temperature	-22°F to +140°F (-30°C to +60°C)
