Basic Troubleshooting: Power-Up Error Codes 9-3
9.3.2 ASTRO Digital Spectra Plus
Table 9-2. ASTRO Digital Spectra Plus Power-Up Error Codes
Error Code Description
Error
Type
Corrective Action
ERROR 01/02 FLASH ROM Codeplug
Checksum
NON-
FATAL
Reprogram the codeplug.
ERROR 01/12 Security Partition
Checksum
NON-
FATAL
Reprogram the security
partition.
ERROR 01/22 Tuning Codeplug
Checksum
NON-
FATAL
Reprogram the tuning
partition.
FAIL 01/81 FLASH ROM Checksum FATAL Reprogram the radio
firmware.
FAIL 01/82 FLASH ROM Codeplug
Checksum
FATAL Reprogram the codeplug.
FAIL 01/88 External RAM Fail FATAL Turn the radio off, then on.
FAIL 01/90 General Hardware FATAL Turn the radio off, then on.
FAIL 01/92 Security Partition
Checksum
FATAL Reprogram the security
partition.
FAIL 01/93 Flashport AUTHENT
CODE Failure
FATAL Replace the VOCON board.
FAIL 01/98 Internal RAM Fail FATAL Replace the VOCON board.
FAIL 01/A2 Tuning Codeplug
Checksum
FATAL Reprogram the tuning
partition.
FAIL 02/81 DSP ROM Checksum FATAL Reprogram the DSP
firmware.
FAIL 02/88 DSP RAM Fatal Error FATAL Turn the radio off, then on.
FAIL 02/90 General DSP Hardware
Failure
FATAL Turn the radio off, then on.
ERROR 05/10 Control Head Hardware
Error
NON-
FATAL
Turn the radio off, then on.
FAIL 05/81 Control Head ROM
Checksum Error
FATAL Replace the control head.
ERROR 06/10 Aux Control Head
Hardware Error
NON-
FATAL
Turn the radio off, then on.
FAIL 06/81 Aux Control Head ROM
Checksum Error
FATAL Replace the aux. control
head.
ERROR 08/10 Siren Hardware Error NON-
FATAL
Turn the radio off, then on.

Motorola ASTRO SPECTRA Specifications

General

Frequency Range	136-174 MHz, 403-470 MHz
Number of Channels	Up to 255
Channel Spacing	12.5 kHz, 20 kHz, 25 kHz
Modulation	FM
Operating Temperature	-22°F to +140°F (-30°C to +60°C)
