Motorola ASTRO SPECTRA Service Manual

x List of Figures
February 3, 2003 6881076C20-E
Figure 11-4. Model W9 Pushbutton Control Head Exploded View.......................................................... 11-5
Figure 11-5. Low-Power (15W) Radio Exploded View ............................................................................ 11-6
Figure 11-6. Mid-Power (20-40/25-50/35W) Radio Exploded View......................................................... 11-7
Figure 11-7. High-Power (50-110W) Radio Exploded View .................................................................... 11-8
Figure 11-8. Motorcycle Interconnect Board and Assembly (HLN6365) Exploded View ........................ 11-9
Figure 11-9. Low- and Mid-Power Interconnect Board and Assembly (HLN6344) Exploded View......... 11-9

Motorola ASTRO SPECTRA Specifications

General

Frequency Range	136-174 MHz, 403-470 MHz
Number of Channels	Up to 255
Channel Spacing	12.5 kHz, 20 kHz, 25 kHz
Modulation	FM
Operating Temperature	-22°F to +140°F (-30°C to +60°C)
