Item Number Description
1 Micro-USB port
3.6.1
Charging a Stand-Alone Battery with the Drop-in Tray Charger
Procedure:
1 To charge the battery, insert the connector of the power supply into the micro Universal Serial
Bus (USB) port on the front of the drop-in tray charger.
2 Connect the power supply to a proper AC outlet.
3 Insert the battery into the tray, with the inside surface of the battery facing the front of the
charger. See Stand-Alone Battery on page 22.
4 Ensure that the slots in the battery are correctly engaged in the charger.
3.6.2
Estimated Charging Time
The following tables provide the estimated charging time of the battery.
Table 5: Estimated Charging Time
Charging Solution Battery Type
Standard Lithium-Ion Bat-
tery
High Capacity Lithium-Ion
Battery
Single Unit Charger 4 hours 5.5 hours
Multi-Unit Charger 2.5 hours 4 hours
3.7
Charging Radio with the Drop-in Tray SUC
Procedure:
1 Place the drop-in Tray Single Unit Charger (SUC) on a flat surface.
2 Insert the connector of the power supply into the Micro USB port on the front of the drop-in tray
charger.
3 Connect the correct power supply to a proper AC outlet.
4 Insert the radio with battery installed into the tray, facing down and making sure that the
charging contacts on the charger are aligned with the contacts on the radio.
68012000044-ED
Chapter 3 : Battery and Charger
23
