Figure 11: Programming the Radio through a Multi-Unit Charger
2 After the radio is connected, open the CPS and select Read on the toolbar to get the radio
profile.
You can change the general, audio, menu, channels, scan list, customize PL/DPL settings,
bluetooth
3
and select frequencies and PL/DPL codes on each channel.
3 To save the settings, select Write to radio on the toolbar.
NOTE: For more information on the CPS, see Help menu in the CPS.
4.2
Factory Default Settings
Your radio is programmed at the factory to the following settings.
Table 8: CLP1010 1W UHF 1 CH Radios Default Settings-BRUS
Channel Num-
ber
Frequency # Frequency Set-
tings (MHz)
Code Value
(Hz)
Bandwidth
(kHz)
1 2 464.5500 67.0 12.5
Table 9: CLP1040 1W UHF 4 CH Radios Default Settings-BRUS
Channel Num-
ber
Frequency # Frequency Set-
tings (MHz)
Code Value
(Hz)
Bandwidth
(kHz)
1 2 464.5500 67.0 12.5
2 8 467.9250 67.0 12.5
3
Bluetooth is available in selected models only
68012000044-ED
Chapter 4 : Radio Programming through CPS
29
