Motorola EVX S24

REF DESCRIPTION VALUE V/W TOL. MFR'S DESIG Part No. SIDE LAY ADR
C1642 CHIP CAP. 330pF 25V B GRM033B11E331KA01D K22147706 B b4
C1643 CHIP CAP. 330pF 25V B GRM033B11E331KA01D K22147706 B b4
C1644 CHIP CAP. 0.1uF 10V B K22107707 K22107707 B a2
C1645 CHIP CAP. 0.1uF 10V B K22107707 K22107707 B a2
C1646 CHIP CAP. 0.1uF 10V B K22107707 K22107707 B a2
C1647 CHIP CAP. 0.1uF 10V B K22107707 K22107707 B a2
C1648 CHIP CAP. 0.1uF 10V B K22107707 K22107707 B a2
C1649 CHIP CAP. 330pF 25V B GRM033B11E331KA01D K22147706 B b4
C1650 CHIP CAP. 330pF 25V B GRM033B11E331KA01D K22147706 B b4
C1651 CHIP CAP. 330pF 25V B GRM033B11E331KA01D K22147706 B b4
C1652 CHIP CAP. 330pF 25V B GRM033B11E331KA01D K22147706 B b4
C1653 CHIP CAP. 330pF 25V B GRM033B11E331KA01D K22147706 B b4
C1654 CHIP CAP. 2.2uF 6.3V B OBS-JMK105BJ225KV-F K22088805 B a5
C1655 CHIP CAP. 2.2uF 6.3V B OBS-JMK105BJ225KV-F K22088805 B
a5
C1656 CHIP CAP. 2.2uF 6.3V B OBS-JMK105BJ225KV-F K22088805 B a5
C1657 CHIP CAP. 2.2uF 6.3V B OBS-JMK105BJ225KV-F K22088805 B a5
C1658 CHIP CAP. 2.2uF 6.3V B OBS-JMK105BJ225KV-F K22088805 B a5
C1659 CHIP CAP. 2.2uF 6.3V B OBS-JMK105BJ225KV-F K22088805 B a5
C1660 CHIP CAP. 0.1uF 10V B K22107707 K22107707 B a2
C1661 CHIP CAP. 330pF 25V B GRM033B11E331KA01D K22147706 B b4
C1662 CHIP CAP. 10uF 6.3V B CEJMK212BJ106KG-T K22080802 B b4
C1663 CHIP CAP. 0.1uF 10V B K22107707 K22107707 B a2
C1664 CHIP CAP. 330pF 25V B GRM033B11E331KA01D K22147706 B b4
C1665 CHIP CAP. 0.1uF 10V B K22107707 K22107707 B a2
C1666 CHIP CAP. 330pF 25V B GRM033B11E331KA01D K22147706 B b4
C1667 CHIP CAP. 0.1uF 10V B K22107707 K22107707 B a2
C1668 CHIP CAP. 330pF 25V B GRM033B11E331KA01D K22147706 B b4
C1669 CHIP CAP. 0.1uF 10V B K22107707 K22107707 B a2
C1670 CHIP CAP. 330pF 25V B GRM033B11E331KA01D K22147706
Bb4
C1671 CHIP CAP. 0.1uF 10V B K22107707 K22107707 B a2
C1672 CHIP CAP. 0.1uF 10V B K22107707 K22107707 B a2
C1673 CHIP CAP. 0.1uF 10V B OBS-LMK105BJ104KV-F K22108802 A B1
C1674 CHIP CAP. 0.1uF 10V B OBS-LMK105BJ104KV-F K22108802 A B1
C1675 CHIP CAP. 390pF 50V B GRM155B11H391KA01D K22178804 A C3
C1700 CHIP CAP. 1uF 10V B OBS-LMK105BJ105KV-F K22108809 B c4
C1701 CHIP CAP. 470pF 16V X7R GRM033R71C471KA01D 21012193001 A C2
C1702 CHIP CAP. 470pF 16V X7R GRM033R71C471KA01D 21012193001 A C2
C1703 NOTPLACED A C2
C1704 NOTPLACED A C2
C1705 CHIP CAP. 1uF 25V X5R GRM155R61E105KE11D CA000987A01 A C2
C1706 CHIP CAP. 680pF 50V B OBS-EMK105BJ153KV-F K22178807 A C2
C1707 NOTPLACED A C2
C1708 NOTPLACED A C2
C1709 NOTPLACED A B1
C1710 NOTPLACED A C2
C1711 NOTPLACED A C2
MN006437A01-AB
Chapter 8: Main Unit (PC003006A01)
61
