Motorola EVX S24

REF DESCRIPTION VALUE V/W TOL. MFR'S DESIG Part No. SIDE LAY ADR
C1712 CHIP CAP. 0.1uF 10V B OBS-LMK105BJ104KV-F K22108802 A B1
C1713 CHIP CAP. 0.022uF 16V B GRM155B11C223KA01D K22128806 A A3
C1714 CHIP TA.CAP. 10uF 16V K78120095 K78120095 A C2
C1715 CHIP TA.CAP. 10uF 16V K78120095 K78120095 A C2
C1718 CHIP CAP. 1uF 25V X5R GRM155R61E105KE11D CA000987A01 A C2
C1719 CHIP CAP. 0.1uF 16V X5R GRM033R61C104KE84D 21013083001 A C2
C1720 CHIP CAP. 0.22uF 16V X7R GRM155R71C223KA01 2113946A02 A C2
C1721 CHIP CAP. 470pF 16V X7R GRM033R71C471KA01D 21012193001 A C2
C1723 CHIP CAP. 1uF 10V X5R 0402ZD104KAT2A 2113946B04 A C2
C1724 CHIP CAP. 680pF 50V B OBS-EMK105BJ153KV-F K22178807 A C2
C1725 CHIP CAP. 0.47uF 16V X5R GRT155R61C474KE01D CA002214A01 A C2
C1726 CHIP TA.CAP. 10uF 16V K78120095 K78120095 A C2
C1727 NOTPLACED A C2
D1001 DIODE UDZV TE-17 16B G2071559 B a6
D1002 SURGE ABSORBER 0603ESDA2-TR2 Q9000981 A A1
D1003 DIODE UDZV TE-17 6.2B G2071557
AA6
D1006 DIODE UDZV TE-17 6.2B G2071557 A A6
D1009 DIODE RN142STE61 G2070994 B c2
D1011 DIODE 1SS390TE61 G2071226 B c2
D1012 DIODE UDZV TE-17 6.2B G2071557 A A6
D1013 DIODE UDZV TE-17 16B G2071559 B a6
D1014 DIODE 1SS390TE61 G2071226 B c2
D1015 DIODE RB751S40T1G G2070850 B a5
D1025 DIODE 1SS400GT2R G2070934 B c4
D1027 DIODE DE2705100L G2071478 A B1
D1029 DIODE 1SV279(TPH3,F) G2070618 B b2
D1030 DIODE 1SV280(TPH3,F) G2070550 B b2
D1031 DIODE 1SV280(TPH3,F) G2070550 B b2
D1032 DIODE 1SV279(TPH3,F) G2070618 B b2
D1035 LED CRGB1313F-TR G2071396 A B1
D1036 DIODE RB751S40T1G G2070850 B a5
D1037 DIODE RB751S40T1G G2070850 B a5
D1038 DIODE RB751S40T1G G2070850 B a5
D1040 DIODE RB751S40T1G G2070850 B a5
D1041 DIODE RB751S40T1G G2070850 B a5
D1042 DIODE 1SS400GT2R G2070934 B c4
D1043 DIODE 1SS400GT2R G2070934 B c4
D1044 DIODE 1SS400GT2R G2070934 B c4
D1047 DIODE UDZV TE-17 16B G2071559 B a6
D1048 DIODE 1SS400GT2R G2070934 B c4
D1049 DIODE 1SS400GT2R G2070934 B c4
D1050 DIODE 1SS400GT2R G2070934 B c4
D1053 DIODE RN142STE61 G2070994 B c2
D1054 DIODE DE2705100L G2071478 A B1
D1055 DIODE MA4E1338B1-287T G2071629 B B2
D1058 DIODE RN142STE61 G2070994 B c2
MN006437A01-AB
Chapter 8: Main Unit (PC003006A01)
62
