Motorola EVX S24

REF DESCRIPTION VALUE V/W TOL. MFR'S DESIG Part No. SIDE LAY ADR
Q1049 TRANSISTOR 2SC4617TLR G3346178R A B1
Q1050 IC SN74AUC1GU04YZPR G1094915 A C4
Q1051 TRANSISTOR 2SC4617TLR G3346178R A B1
Q1052 FET RUM002N02GT2L G3070455 B a5
Q1053 TRANSISTOR 2SA1774TLR G3117748R B c4
Q1054 IC TS3USB221ARSER G1094963 A A5
Q1055 TRANSISTOR 2SA1774TLR G3117748R B c4
Q1057 TRANSISTOR DTC144EETL G3070075 B c5
Q1058 FET RUM002N02GT2L G3070455 B a5
Q1059 FET RUM002N02GT2L G3070455 B a5
Q1060 TRANSISTOR DTC144EETL G3070075 B c5
Q1061 TRANSISTOR DTC144EETL G3070075 B c5
Q1063 FET RZM002P02T2L G3070432 A B5
Q1069 FET RUM002N02GT2L G3070455 B a5
Q1070 FET RUM002N02GT2L G3070455 B a5
Q1071 FET RUM002N02GT2L G3070455 B a5
Q1072 IC NJM2730F-TE1 G1095450 B b1
Q1073 FET RUM002N02GT2L G3070455 B a5
Q1074 TRANSISTOR DTC144EETL G3070075 B c5
Q1075 TRANSISTOR UMD5NTR G3070343 A B2
Q1076 TRANSISTOR 2SC4617TLR G3346178R A
B1
Q1077 FET RZM002P02T2L G3070432 A B5
Q1078 FET RUM002N02GT2L G3070455 B a5
Q1079 FET RUM002N02GT2L G3070455 B a5
Q1080 TRANSISTOR DTC114TETL G3070225 B c1
Q1601 IC MT29F1G16ABBDAH4-ITX:D G1095000 A C4
Q1602 IC SN74AVC2T245RSWR G1094993 A B5
Q1604 IC OMAPL138EZCEA3R G1095004 A B4
Q1605 IC MT46H32M16LFBF-5 IT:C G1094918 A A4
Q1606 IC SN74AVC2T245RSWR G1094993 A B5
Q1607 IC SN74AVC2T245RSWR G1094993 A B5
R1001 CHIP RES. 4.7k 1/16W 0.01 RMC1/16SK472FTH J24189488 B c4
R1002 CHIP RES. 4.7k 1/16W 0.01 RMC1/16SK472FTH J24189488 B c4
R1003 CHIP RES. 4.7k 1/16W 0.01 RMC1/16SK472FTH J24189488 B c4
R1004 CHIP RES. 22k 1/16W 0.01 RMC1/16SK223FTH J24189492 B c5
R1005 CHIP RES. 47k 1/16W 0.05 RMC1/16-473JTP J24185473 B c1
R1007 CHIP RES. 15k 1/16W 0.01 RMC1/16SK153FTH J24189491 B c5
R1008 CHIP RES. 10k 1/16W 0.01 J24189489 J24189489 B c5
R1009 CHIP RES. 470k 1/16W 0.01 J24189537 J24189537 B c5
R1010
CHIP RES. 470k 1/16W 0.01 J24189537 J24189537 B c5
R1011 CHIP RES. 5.6k 1/16W 0.01 J24189520 J24189520 B c5
R1013 CHIP RES. 1k 1/16W 0.01 RMC1/16SK102FTH J24189487 B c4
R1014 CHIP RES. 470k 1/16W 0.01 J24189537 J24189537 B c5
R1016 CHIP RES. 68 1/16W 0.05 RMC1/16S-680JTH J24189011 A A1
R1017 CHIP RES. 68 1/16W 0.05 RMC1/16S-680JTH J24189011 A A1
R1018 CHIP RES. 470k 1/16W 0.01 J24189537 J24189537 B c5
MN006437A01-AB
Chapter 8: Main Unit (PC003006A01)
66
