Motorola EVX S24

REF DESCRIPTION VALUE V/W TOL. MFR'S DESIG Part No. SIDE LAY ADR
R1019 CHIP RES. 0.2 1/2W 0.01 RLC32-R200FTP J24279031 A B3
R1020 CHIP RES. 0.2 1/2W 0.01 RLC32-R200FTP J24279031 A B3
R1021 CHIP RES. 2.2k 1/16W 0.01 RMC1/16SK222FTH J24189497 A B2
R1022 CHIP RES. 0 1/16W 0.05 RMC1/16SJPTH J24189070 A B2
R1023 CHIP RES. 330k 1/16W 0.005 J24189330 J24189330 A B2
R1024 CHIP RES. 270k 1/16W 0.005 MCR01MZPD2703 J24189329 A B2
R1025 CHIP RES. 100 1/16W 0.01 RMC1/16SK101FTH J24189504 B b5
R1028 CHIP RES. 2.2M 1/16W 0.005 RGC1/16SK225DTH J24189599 A B2
R1030 CHIP RES. 0 1/16W 0.05 RMC1/16SJPTH J24189070 A B2
R1031 CHIP RES. 47k 1/16W 0.01 RMC1/16SK473FTH J24189525 A A6
R1032 CHIP RES. 2.2M 1/16W 0.005 RGC1/16SK225DTH J24189599 A B2
R1033 CHIP RES. 4.7k 1/16W 0.01 RMC1/16SK472FTH J24189488 B c4
R1034 CHIP RES. 10k 1/16W 0.01 J24189489 J24189489 B c5
R1037 CHIP RES. 47k 1/16W 0.01 RMC1/16SK473FTH J24189525 A
A6
R1038 CHIP RES. 1k 1/16W 0.01 RMC1/16SK102FTH J24189487 B c4
R1039 CHIP RES. 100k 1/16W 0.005 J24189386 J24189386 B a5
R1041 CHIP RES. 68k 1/16W 0.01 J24189527 J24189527 B a5
R1042 CHIP RES. 22k 1/16W 0.01 RMC1/16SK223FTH J24189492 B c5
R1045 CHIP RES. 560k 1/16W 0.01 RMC1/16SK564FTH J24189538 B a5
R1046 CHIP RES. 220k 1/16W 0.01 J24189533 J24189533 A A2
R1047 CHIP RES. 15k 1/16W 0.01 RMC1/16SK153FTH J24189491 B c5
R1048 CHIP RES. 15k 1/16W 0.01 RMC1/16SK153FTH J24189491 B c5
R1049 CHIP RES. 22 1/16W 0.05 RMC1/16S-220JTH J24189005 A A5
R1050 CHIP RES. 22 1/16W 0.05 RMC1/16S-220JTH J24189005 A A5
R1051 CHIP RES. 100 1/16W 0.01 RMC1/16SK101FTH J24189504 B b5
R1052 CHIP RES. 2.2M 1/16W 0.005 RGC1/16SK225DTH J24189599 A B2
R1053 CHIP RES. 470 1/16W 0.01 RMC1/16SK471FTH J24189512 A A3
R1055 CHIP RES. 1.2k 1/16W 0.01 J24189515 J24189515 B a5
R1056 CHIP RES. 27k 1/16W 0.01 RMC1/16SK273FTH J24189493
AA2
R1057 CHIP RES. 4.7k 1/16W 0.01 RMC1/16SK472FTH J24189488 B c4
R1058 CHIP RES. 1.2k 1/16W 0.01 J24189515 J24189515 B a5
R1062 CHIP RES. 4.7k 1/16W 0.01 RMC1/16SK472FTH J24189488 B c4
R1063 CHIP RES. 4.7k 1/16W 0.01 RMC1/16SK472FTH J24189488 B c4
R1065 CHIP RES. 100 1/16W 0.01 RMC1/16SK101FTH J24189504 B b5
R1066 CHIP RES. 330k 1/16W 0.01 RMC1/16SK334FTH J24189535 A B2
R1067 CHIP RES. 470k 1/16W 0.01 J24189537 J24189537 B c5
R1069 CHIP RES. 390k 1/16W 0.01 RMC1/16SK394FTH J24189536 B b5
R1070 CHIP RES. 22k 1/16W 0.01 RMC1/16SK223FTH J24189492 B c5
R1071 CHIP RES. 22k 1/16W 0.01 RMC1/16SK223FTH J24189492 B c5
R1072 CHIP RES. 470k 1/16W 0.01 J24189537 J24189537 B c5
R1073 CHIP RES. 10k 1/16W 0.01 J24189489 J24189489 B c5
R1074 CHIP RES. 15k 1/16W 0.01 RMC1/16SK153FTH J24189491 B c5
R1075 CHIP RES. 0 1/16W 0.05 RMC1/16SJPTH J24189070 A B2
R1076 CHIP RES. 470 1/16W 0.01 RMC1/16SK471FTH
J24189512 A A3
R1077 CHIP RES. 1k 1/16W 0.01 RMC1/16SK102FTH J24189487 B c4
R1078 CHIP RES. 100 1/16W 0.01 RMC1/16SK101FTH J24189504 B b5
MN006437A01-AB
Chapter 8: Main Unit (PC003006A01)
67
