Motorola EVX S24

REF DESCRIPTION VALUE V/W TOL. MFR'S DESIG Part No. SIDE LAY ADR
R1079 CHIP RES. 8.2k 1/16W 0.01 J24189522 J24189522 B c4
R1080 CHIP RES. 2.2k 1/16W 0.01 RMC1/16SK222FTH J24189497 A B2
R1082 NOTPLACED A B1
R1083 CHIP RES. 4.7k 1/16W 0.01 RMC1/16SK472FTH J24189488 B c4
R1085 CHIP RES. 4.7k 1/16W 0.01 RMC1/16SK472FTH J24189488 B c4
R1087 CHIP RES. 4.7k 1/16W 0.01 RMC1/16SK472FTH J24189488 B c4
R1088 CHIP RES. 2.2k 1/16W 0.01 RMC1/16SK222FTH J24189497 A B2
R1089 CHIP RES. 4.7k 1/16W 0.01 RMC1/16SK472FTH J24189488 B c4
R1090 CHIP RES. 22k 1/16W 0.01 RMC1/16SK223FTH J24189492 B c5
R1091 CHIP RES. 10 1/16W 0.05 RMC1/16S-100JTH J24189001 B c4
R1092 CHIP RES. 22 1/16W 0.05 RMC1/16S-220JTH J24189005 A A5
R1093 CHIP RES. 100 1/16W 0.01 RMC1/16SK101FTH J24189504 B b5
R1094 CHIP RES. 330 1/16W 0.01 RMC1/16SK331FTH J24189510 B c4
R1095 CHIP RES. 1.2k 1/16W 0.05 ERJ2GEJ122X 0613952Q75 B B2
R1096 CHIP RES. 330 1/16W
0.01 RMC1/16SK331FTH J24189510 B c4
R1097 CHIP RES. 330 1/16W 0.01 RMC1/16SK331FTH J24189510 B c4
R1098 CHIP RES. 12k 1/16W 0.01 J24189490 J24189490 B c4
R1099 CHIP RES. 4.7 1/16W 0.05 J24189066 J24189066 B c4
R1101 CHIP RES. 47k 1/16W 0.01 RMC1/16SK473FTH J24189525 A A6
R1102 CHIP RES. 2.7 1/16W 0.05 RMC1/16S 2R7JTH J24189503 A C5
R1103 CHIP RES. 2.7 1/16W 0.05 RMC1/16S 2R7JTH J24189503 A C5
R1104 CHIP RES. 0 1/16W 0.05 RMC1/16SJPTH J24189070 A B2
R1106 CHIP RES. 0 1/16W 0.05 RMC1/16SJPTH J24189070 A B2
R1107 CHIP RES. 4.7k 1/16W 0.01 RMC1/16SK472FTH J24189488 B c4
R1111 CHIP RES. 560 1/16W 0.01 J24189513 J24189513 B c4
R1112 CHIP RES. 10k 1/16W 0.01 J24189489 J24189489 B c5
R1113 CHIP RES. 15k 1/16W 0.01 RMC1/16SK153FTH J24189491 B c5
R1114 CHIP RES. 100 1/16W 0.01 RMC1/16SK101FTH J24189504 B b5
R1115 CHIP RES. 4.7k 1/16W 0.01 RMC1/16SK472FTH J24189488 B c4
R1116 CHIP RES. 22k
1/16W 0.01 RMC1/16SK223FTH J24189492 B c5
R1117 CHIP RES. 2.2k 1/16W 0.01 RMC1/16SK222FTH J24189497 A B2
R1119 CHIP RES. 4.7k 1/16W 0.01 RMC1/16SK472FTH J24189488 B c4
R1120 CHIP RES. 270 1/16W 0.01 J24189509 J24189509 B c4
R1121 CHIP RES. 220 1/16W 0.05 ERJ2GEJ221X 0613952Q57 B B2
R1122 CHIP RES. 15 1/16W 0.05 RMC1/16S-150JTH J24189003 B c4
R1123 CHIP RES. 3.3k 1/16W 0.005 RR0510P-332-D J24189131 B b3
R1124 CHIP RES. 2.7k 1/16W 0.005 RR0510P-272-D J24189129 B b3
R1125 CHIP RES. 10k 1/16W 0.01 J24189489 J24189489 B c5
R1126 CHIP RES. 4.7k 1/16W 0.01 RMC1/16SK472FTH J24189488 B c4
R1127 CHIP RES. 100k 1/16W 0.01 RMC1/16SK104FTH J24189529 A C6
R1128 CHIP RES. 270 1/16W 0.01 J24189509 J24189509 B c4
R1129 CHIP RES. 1k 1/16W 0.01 RMC1/16SK102FTH J24189487 B c4
R1131 CHIP RES. 10k 1/16W 0.01 J24189489 J24189489 B c5
R1132 CHIP RES. 47 1/16W 0.05 RMC1/16S-470JTH J24189009 B b2
R1133 CHIP RES.
470 1/16W 0.01 RMC1/16SK471FTH J24189512 A A3
R1134 CHIP RES. 56 1/16W 0.005 RR0510R-560-D J24189089 B b3
MN006437A01-AB
Chapter 8: Main Unit (PC003006A01)
68
