Motorola EVX S24

REF DESCRIPTION VALUE V/W TOL. MFR'S DESIG Part No. SIDE LAY ADR
R1208 CHIP RES. 0 1/20W 0.05 RMC1/20JPPA J24175000 B a3
R1209 CHIP RES. 0 1/20W 0.05 RMC1/20JPPA J24175000 B a3
R1210 CHIP RES. 0 1/20W 0.05 RMC1/20JPPA J24175000 B a3
R1211 CHIP RES. 0 1/20W 0.05 RMC1/20JPPA J24175000 B a3
R1212 CHIP RES. 0 1/20W 0.05 RMC1/20JPPA J24175000 B a3
R1213 CHIP RES. 220k 1/16W 0.01 J24189533 J24189533 A A2
R1214 CHIP RES. 47k 1/16W 0.01 RMC1/16SK473FTH J24189525 A A6
R1215 CHIP RES. 47k 1/16W 0.01 RMC1/16SK473FTH J24189525 A A6
R1216 CHIP RES. 10k 1/20W 0.05 RMC1/20-103JPA J24175103 B a3
R1217 CHIP RES. 0 1/20W 0.05 RMC1/20JPPA J24175000 B a3
R1218 CHIP RES. 10k 1/20W 0.05 RMC1/20-103JPA J24175103 B a3
R1219 CHIP RES. 47k 1/16W 0.01 RMC1/16SK473FTH J24189525 A A6
R1220 CHIP RES. 100 1/16W 0.01 RMC1/16SK101FTH J24189504 B b5
R1221 CHIP RES. 47 1/16W 0.05 RMC1/16S-470JTH J24189009 B
b2
R1222 CHIP RES. 47 1/16W 0.05 RMC1/16S-470JTH J24189009 B b2
R1223 CHIP RES. 0 1/16W 0.05 RMC1/16SJPTH J24189070 A B2
R1224 CHIP RES. 82 1/16W 0.05 RMC1/16S-820JTH J24189012 A B4
R1225 CHIP RES. 10k 1/20W 0.05 RMC1/20-103JPA J24175103 B a3
R1226 CHIP RES. 12k 1/16W 0.01 J24189490 J24189490 B c4
R1227 CHIP RES. 47 1/16W 0.05 RMC1/16S-470JTH J24189009 B b2
R1228 CHIP RES. 82 1/16W 0.05 RMC1/16S-820JTH J24189012 A B4
R1229 CHIP RES. 47 1/16W 0.05 RMC1/16S-470JTH J24189009 B b2
R1230 CHIP RES. 0 1/16W 0.05 RMC1/16SJPTH J24189070 A B2
R1231 CHIP RES. 0 1/16W 0.05 RMC1/16SJPTH J24189070 A B2
R1232 CHIP RES. 0 1/16W 0.05 RMC1/16SJPTH J24189070 A B2
R1233 CHIP RES. 0 1/16W 0.05 RMC1/16SJPTH J24189070 A B2
R1234 CHIP RES. 0 1/16W 0.05 RMC1/16SJPTH J24189070 A B2
R1235 CHIP RES. 100 1/16W 0.01 RMC1/16SK101FTH J24189504 B b5
R1238 CHIP RES. 47k 1/16W 0.01 RMC1/16SK473FTH J24189525
AA6
R1240 CHIP RES. 330k 1/16W 0.01 RMC1/16SK334FTH J24189535 A B2
R1241 CHIP RES. 0 1/16W 0.05 RMC1/16SJPTH J24189070 A B2
R1242 CHIP RES. 330 1/16W 0.01 RMC1/16SK331FTH J24189510 B c4
R1243 CHIP RES. 330 1/16W 0.01 RMC1/16SK331FTH J24189510 B c4
R1245 CHIP RES. 220k 1/16W 0.01 J24189533 J24189533 A A2
R1250 CHIP RES. 10k 1/16W 0.01 J24189489 J24189489 B c5
R1251 CHIP RES. 10k 1/16W 0.01 J24189489 J24189489 B c5
R1252 CHIP RES. 0 1/16W 0.05 RMC1/16JPTP J24185000 A C2
R1253 CHIP RES. 470 1/16W 0.01 RMC1/16SK471FTH J24189512 A A3
R1254 CHIP RES. 100 1/16W 0.01 RMC1/16SK101FTH J24189504 B b5
R1255 CHIP RES. 4.7k 1/16W 0.01 RMC1/16SK472FTH J24189488 B c4
R1256 CHIP RES. 220k 1/16W 0.01 J24189533 J24189533 A A2
R1257 CHIP RES. 2.2M 1/16W 0.005 RGC1/16SK225DTH J24189599 A B2
R1258 CHIP RES. 10k 1/16W 0.01 J24189489 J24189489 B c5
R1259 CHIP RES. 0 1/16W 0.05 RMC1/16JPTP
J24185000 A C2
R1260 CHIP RES. 2.2M 1/16W 0.005 RGC1/16SK225DTH J24189599 A B2
R1261 CHIP RES. 150k 1/16W 0.01 RMC1/16SK154FTH J24189531 A C3
MN006437A01-AB
Chapter 8: Main Unit (PC003006A01)
70
