Motorola EVX S24

REF DESCRIPTION VALUE V/W TOL. MFR'S DESIG Part No. SIDE LAY ADR
R1262 CHIP RES. 220k 1/16W 0.01 J24189533 J24189533 A A2
R1263 CHIP RES. 2.2M 1/16W 0.005 RGC1/16SK225DTH J24189599 A B2
R1266 CHIP RES. 4.7k 1/16W 0.01 RMC1/16SK472FTH J24189488 B c4
R1269 CHIP RES. 100 1/16W 0.01 RMC1/16SK101FTH J24189504 B b5
R1270 CHIP RES. 10k 1/16W 0.01 J24189489 J24189489 B c5
R1271 CHIP RES. 10k 1/16W 0.01 J24189489 J24189489 B c5
R1272 CHIP RES. 0 1/16W 0.05 RMC1/16SJPTH J24189070 A B2
R1275 CHIP RES. 220 1/16W 0.01 RMC1/16SK221FTH J24189508 B b3
R1276 CHIP RES. 1k 1/16W 0.01 RMC1/16SK102FTH J24189487 B c4
R1277 CHIP RES. 100 1/16W 0.01 RMC1/16SK101FTH J24189504 B b5
R1279 CHIP RES. 1M 1/16W 0.01 RMC1/16SK105FTH J24189541 B a2
R1280 CHIP RES. 1M 1/16W 0.01 RMC1/16SK105FTH J24189541 B a2
R1282 CHIP RES. 100 1/16W 0.01 RMC1/16SK101FTH J24189504 B b5
R1287 CHIP RES. 1M 1/16W 0.01 RMC1/16SK105FTH J24189541 B
a2
R1289 CHIP RES. 10k 1/16W 0.01 J24189489 J24189489 B c5
R1290 CHIP RES. 4.7k 1/16W 0.01 RMC1/16SK472FTH J24189488 B c4
R1291 CHIP RES. 4.7k 1/16W 0.01 RMC1/16SK472FTH J24189488 B c4
R1295 CHIP RES. 47k 1/16W 0.01 RMC1/16SK473FTH J24189525 A A6
R1296 CHIP RES. 1k 1/16W 0.01 RMC1/16SK102FTH J24189487 B c4
R1300 CHIP RES. 330 1/16W 0.01 RMC1/16SK331FTH J24189510 B c4
R1301 CHIP RES. 100k 1/16W 0.01 RMC1/16SK104FTH J24189529 A C6
R1302 CHIP RES. 2.2k 1/16W 0.01 RMC1/16SK222FTH J24189497 A B2
R1307 CHIP RES. 0 1/16W 0.05 RMC1/16SJPTH J24189070 A B2
R1308 CHIP RES. 2.2k 1/16W 0.01 RMC1/16SK222FTH J24189497 A B2
R1309 CHIP RES. 2.2k 1/16W 0.01 RMC1/16SK222FTH J24189497 A B2
R1310 CHIP RES. 2.2k 1/16W 0.01 RMC1/16SK222FTH J24189497 A B2
R1316 CHIP RES. 22k 1/16W 0.01 RMC1/16SK223FTH J24189492 B c5
R1317 CHIP RES. 0 1/16W 0.05 RMC1/16SJPTH J24189070 A B2
R1322 CHIP RES. 22 1/16W 0.05 RMC1/16S-220JTH J24189005
AA5
R1323 CHIP RES. 0 1/16W 0.05 RMC1/16SJPTH J24189070 A B2
R1328 CHIP RES. 100 1/16W 0.01 RMC1/16SK101FTH J24189504 B b5
R1329 CHIP RES. 10k 1/16W 0.01 J24189489 J24189489 B c5
R1330 CHIP RES. 22k 1/16W 0.01 RMC1/16SK223FTH J24189492 B c5
R1331 CHIP RES. 1k 1/16W 0.01 RMC1/16SK102FTH J24189487 B c4
R1332 CHIP RES. 330 1/16W 0.01 RMC1/16SK331FTH J24189510 B c4
R1334 CHIP RES. 4.7k 1/16W 0.01 RMC1/16SK472FTH J24189488 B c4
R1335 CHIP RES. 4.7k 1/16W 0.01 RMC1/16SK472FTH J24189488 B c4
R1336 CHIP RES. 4.7k 1/16W 0.01 RMC1/16SK472FTH J24189488 B c4
R1337 CHIP RES. 82k 1/16W 0.01 RMC1/16SK823FTH J24189528 A B2
R1338 CHIP RES. 1k 1/16W 0.01 RMC1/16SK102FTH J24189487 B c4
R1340 CHIP RES. 0 1/16W 0.05 RMC1/16SJPTH J24189070 A B2
R1341 CHIP RES. 0 1/16W 0.05 RMC1/16SJPTH J24189070 A B2
R1343 CHIP RES. 470 1/16W 0.01 RMC1/16SK471FTH J24189512 A A3
R1344 CHIP RES. 470k 1/16W 0.01 J24189537
J24189537 B c5
R1345 CHIP RES. 4.7k 1/16W 0.01 RMC1/16SK472FTH J24189488 B c4
R1346 CHIP RES. 0 1/16W 0.05 RMC1/16SJPTH J24189070 A B2
MN006437A01-AB
Chapter 8: Main Unit (PC003006A01)
71
