Number Description
2 Remote Expansion Head PMLN4904_
NOTICE: Possible use of Data Expansion Control Head Enhanced
PMLN4908_.
3 Cable Expansion Head to Control Head
4 Remote Mount Enhanced Control Head
Table 45: Associated Components for Remote Mount
Item Description Part Number
1 Remote Mount Cable – 3 m, 5 m, 7 m, 10 m RKN4077_, RKN4078_, RKN4079_,
PMKN4020_
2 Remote Head Enhanced or Data Expansion
Head Enhanced
PMLN4904_ or PMLN4908_
NOTICE:
Vehicle installations require attention to the effects of EMC and over long cable runs additional
protection may be required. Motorola has suitable suppression kits such as Part Number
01015001001 Toroid EMC Suppression Kit.
Wind the Remote Mount Cable ten times around each toroid.
Place each toroid 30.0±2.5 cm respectively from the expansion head and the control head.
Winding at both ends reduces the effective cable length approximately by 0.8 m.
Fix the toroids firmly to a stable surface once the Remote Mount Cable is connected.
4.3.1
Installing the Remote Mount Enhanced Control Head onto the
Remote Mount Trunnion
When and where to use: Follow these steps to install the Remote Mount Enhanced Control Head
onto the Remote Mount Trunnion.
Procedure:
1 Slide the Remote Mount Enhanced Control Head onto the mounting trunnion until it snaps into
place.
2 Tighten the screws at both sides of the trunnion. After a few turns, tilt the control head for an
optimum view of the display. Then, complete the tightening of the screws.
68015000181-LB
Chapter 4: Radio Installation
50 Send Feedback
To Next Page
