Using the Interfaces A - 3
Single-Slot Serial/USB Cradle
Table A-2 summarizes the Single-Slot Serial/USB cradle’s technical specifications.
Table A-2 Single-Slot Serial/USB Cradle Technical Specifications
Item Description
Operating Temperature -32° to 122°F (0° to +50°C)
Storage Temperature -40° to 158°F (-40° to 70°C)
Battery Charging Temperature 32° to 104°F (0° to 40°C)
Humidity 5% to 95% non-condensing at 122° F (50°C)
Electrostatic Discharge (ESD) +/-15 kV (air) (RH 50%); +/- 8 kV (contact)
Drop 30 in. (0.76 m) to vinyl tiled concrete
Shock and Vibration Drop/Shock:
2 times per side (12 drops total of the same unit) from a height of 30 in. (0.76 m) to
concrete at room temperatures
Vibration:
4G's, random, 20 Hz to 2,000 Hz vibration
Cargo/Packaged:
Six (6) foot drop at 23°C, 5 Hz, Vibration < 20 lbs
Vehicle stacking 96", 23°C, and 85% relative humidity
Dimensions 4.00 in. L x 3.25 in. W x 3.00 in. H
(102 mm L x 83 mm W x 77 mm H)
Weight 4.94 oz (140 g)
Interface RS-232, 115.2 kbps max, USB (miniB connector)
