Appendix A Specifications
Technical Specifications
Mobile Computer
Table A-1 summarizes the mobile computer’s intended operating environment.
Table A-1 Mobile Computer Technical Specifications
Item Description
Operating Temperature 14° to 122°F (-10° to +50°C)
Storage Temperature -40° to 158°F (-40° to 70°C)
Battery Charging Temperature -32° to 104°F (0° to 40°C)
Humidity 0% to 85% non-condensing at 122° F (50°C)
Electrostatic Discharge (ESD) +/-15 kV (air) (RH 50%); +/- 8 kV (contact)
Sealing IP54 category 2
Shock and Vibration Drop/Shock:
2 times per side (12 drops total of the same unit) from a height of 3.94 feet (1.2 M)
to concrete at -10°C, 23°C and 50°C
Tumble:
500, ½ meter tumbles (1 tumble = 2 drops)
Vibration:
4G's, random, 5 Hz to 2,000 Hz vibration
Cargo/Packaged:
Six (6) foot drop at 23°C, 5 Hz, Vibration < 20 lbs
Vehicle stacking 96", 23°C, and 85% relative humidity
