Bus Operation
MOTOROLA
MC68030 USER’S MANUAL
7-7
For example, if the processor is executing an instruction that reads a long-word operand
from a long-word aligned address, it attempts to read 32 bits during the first bus cycle. (Refer
to
7.2.2 Misaligned Operands
for the case of a word or byte address.) If the port responds
that it is 32 bits wide, the MC68030 latches all 32 bits of data and continues with the next
operation. If the port responds that it is 16 bits wide, the MC68030 latches the 16 bits of valid
data and runs another bus cycle to obtain the other 16 bits. The operation for an 8-bit port
is similar, but requires four read cycles. The addressed device uses the DSACKx
signals to
indicate the port width. For instance, a 32-bit device
always
returns DSACKx for a 32-bit port
(regardless of whether the bus cycle is a byte, word, or long-word operation).
Dynamic bus sizing requires that the portion of the data bus used for a transfer to or from a
particular port size be fixed. A 32-bit port must reside on data bus bits 0–31, a 16-bit port
must reside on data bus bits 16-32, and an 8-bit port must reside on data bus bits 24-31.
This requirement minimizes the number of bus cycles needed to transfer data to 8- and 16-
bit ports and ensures that the MC68030 correctly transfers valid data. The MC68030 always
attempts to transfer the maximum amount of data on all bus cycles; for a long-word
operation, it always assumes that the port is 32 bit wide when beginning the bus cycle.
The bytes of operands are designated as shown in Figure 7-3. The most significant byte of
a long-word operand is OP0, and OP3 is the least significant byte. The two bytes of a word-
length operand are OP2 (most significant) and OP3. The single byte of a byte-length
operand is OP3. These designations are used in the figures and descriptions that follow.
Table 7-1. DSACK
Codes and Results
DSACK1
DSACK0
Result
H H Insert Wait States in Current Bus Cycle
H L Complete Cycle — Data Bus Port Size is 8 Bits
L H Complete Cycle — Data Bus Port Size is 16 Bits
L L Complete Cycle — Data Bus Port Size is 32 Bits
