7.2.5 MC68030 versus MC68020 Dynamic Bus Sizing
The MC68030 supports the dynamic bus sizing mechanism of the MC68020 for
asynchronous bus cycles (terminated with DSACKx
) with two restrictions. First, for a
cachable access within the boundaries of an aligned long word, the port size must be
consistent throughout the transfer of each long word. For example, when a byte port resides
at address $00, addresses $01, $02, and $03 must also correspond to byte ports. Second,
the port must supply as much data as it signals as port size, regardless of the transfer size
indicated with the size signals and the address offset indicated by A0 and A1 for cachable
accesses. Otherwise, dynamic bus sizing is identical in the two processors.
7.2.6 Cache Filling
The on-chip data and instruction caches, described in Section 6 On-Chip Cache
Memories, are each organized as 16 lines of four long-word entries each. For each line, a
tag contains the most significant bits of the logical address, FC2 (instruction cache) or FC0–
FC2 (data cache), and a valid bit for each entry in the line. An entry fill operation loads an
entire long word accessed from memory into a cache entry. This type of fill operation is
performed when one entry of a line is not valid and an access is cachable. A burst fill
operation is requested when a tag miss occurs for the current cycle or when all four entires
in the cache line are invalid (provided the cache is enabled and burst filling for the cache is
enabled). The burst fill operation attempts to fill all four entries in the line. To support burst
filling, the slave device must have a 32-bit port and must have a burst mode capability; that
is, it must acknowledge a burst request with the cache burst acknowledge (CBACK
) signal.
It must also terminate the burst accesses with STERM
and place a long word on the data
bus for each transfer. The device may continue to supply successive long words, asserting
STERM
with each one, until the cache line is full. For further information about filling the
cache, both entry fills and burst mode fills, refer to 6.1.3 Cache Filling, 7.3.4 Synchronous
Read Cycle, 7.3.5 Synchronous Write Cycle, and 7.3.7 Burst Operation Cycles, which
discuss in detail the required bus cycles.
