Data Organization and Addressing Capabilities
MOTOROLA MC68030 USER’S MANUAL 2-35
(disp,PC)
Simple PC relative.
(disp,PC,Rn)
PC relative with variable index.
(disp,PC,Rn*scale)
PC relative with subscript.
Memory Pointer:
([preindexed])
Memory pointer directly to data operand.
([preindexed],disp)
Memory pointer as base with displacement to data operand.
([postindexed],Rn)
Memory pointer with variable index.
([postindexed],disp,Rn)
Memory pointer with constant and variable index.
([postindexed],Rn*scale)
Memory pointer subscripted.
([postindexed],disp,Rn*scale)
Memory pointer subscripted with constant index.
