Motorola MCS 2000 - Page 160

10-12 Chapter 10: Digrams and Parts Lists
December 6, 2004 68P81083C20-D
Control Head Model I Parts List
Reference
Symbol
MOTOROLA
Part Number Description
CAPACITORS, Fixed:
unless otherwise stated
C0650 2311049J23 10uF
C0651 2113743K15 0.1uF
C0652 2113741F17 470pF
C0653 2113741F49 .01uF
C0654 2113743A23 0.22uF
C0655 2311049J23 10uF
C0656 2113741F17 470pF
C0657 2113741F17 470pF
C0658 2113741F17 470pF
C0659 2113741F17 470pF
C0660 2113741F17 470pF
C0661 2113741F17 470pF
C0662 2113741F17 470pF
C0663 2311049J12 4.7uF
C0664 2113740F39 33pF
C0665 2113740F39 33pF
C0666 2311049J23 10uF
C0667 2113743K15 0.1uF
C0668 2113741F17 470pF
C0669 2113741F17 470pF
C0670 2113741F17 470pF
C0671 2113741F17 470pF
C0672 2113741F17 470pF
C0673 2113741F17 470pF
C0674 2113741F17 470pF
C0675 2113743A23 .220uF
C0690
a
2311049A95 10uF
DIDODES:
D0658 4805729G75 LED GREEN
D0659 4805729G75 LED GREEN
D0660 4805729G75 LED GREEN
D0661 4805729G75 LED GREEN
D0662 4805729G75 LED GREEN
D0663 4805729G75 LED GREEN
D0664 4805729G75 LED GREEN
D0665 4805729G75 LED GREEN
D0666 4805729G75 LED GREEN
D0667 4805729G75 LED GREEN
D0668 4805729G75 LED GREEN
D0669 4805729G75 LED GREEN
D0670 4805729G75 LED GREEN
D0671 4805729G75 LED GREEN
D0672 4805729G75 LED GREEN
D0673 4805729G75 LED GREEN
D0674 4813830A15 DIODE 5.6V
D0675 4813830A15 DIODE 5.6V
D0676 4813830A33 DIODE 20V
D0677 4813830A15 DIODE 5.6V
D0678 4813830A15 DIODE 5.6V
D0679 4805729G73 LED YEL
D0680 4805729G73 LED YEL
D0681 4805729G74 LED RED
D0682 4805729G75 LED GREEN
D0683 4813830A15 DIODE 5.6V
D0684 4813830A15 DIODE 5.6V
D0685 4813830A15 DIODE 5.6V
D0730
1
4805129M12 DIODE
CONNECTORS:
J0650 2805922V01 PLUG VERT
J0652 2809926G01 CONN SUR MT HDR
P0651 2805924V01 CONNECTOR MIC
TRANSISTORS:
Q0650 4813824A17 PNP
Q0651 4813822A20 NPN
Q0652 4813824A10 NPN
Q0653 4813824A17 PNP
Q0654 4813824A10 NPN
Q0655 4813824A10 NPN
Q0656 4813824A17 PNP
Q0657 4813824A17 PNP
Q0658 4813824A10 NPN
Q0659 4813824A10 NPN
Q0660 4813824A10 NPN
Q0661 4813824A10 NPN
Q0662 4813822A08 PNP
Q0663 4813824A10 NPN
RESISTORS, Fixed: ¾
unless otherwise stated
R0650 0662057A59 2.7K
R0651 0662057A77 15K
R0652 0662057A73 10K
R0653 0662057A09 220
Reference
Symbol
MOTOROLA
Part Number Description
R0654 0662057A73 10K
R0655 0662057A61 3.3K
R0656 0662057A85 33K
R0657 0662057A85 33K
R0658 0662057A73 10K
R0659 0662057A73 10K
R0660 0662057A73 10K
R0661 0662057A73 10K
R0662 0662057A73 10K
R0663 0662057A73 10K
R0664 0662057A73 10K
R0665 0662057A89 47K
R0666 0662057A81 22K
R0667 0662057A73 10K
R0668 0662057A73 10K
R0669 0662057A65 4.7K
R0670 0662057A65 4.7K
R0671 0662057A65 4.7K
R0672 0662057A56 2K
R0673 0662057A01 10
R0674 0662057A01 10
R0676 0662057B47 0
R0677 0662057A89 47K
R0678 0662057A97 100K
R0679 0662057A65 4.7K
R0680 0680194M18 51
R0681 0662057A57 2.2K
R0682 0662057A73 10K
R0683 0662057A65 4.7K
R0684 0662057A73 10K
R0685 0662057A73 10K
R0686 0662057A57 2.2K
R0687 0662057A73 10K
R0688 0662057A73 10K
R0689 0662057A73 10K
R0690 0662057A97 100K
R0691 0662057A73 10K
R0692 0662057B22 1M
R0693 0662057A39 390
R0694 0662057A41 470
R0695 0662057A39 390
R0696 0662057A37 330
R0697 0662057A37 330
R0698 1805911V01 Pot Vol
Reference
Symbol
MOTOROLA
Part Number Description
R0699 0662057A73 10K
R0700 0662057B16 560K
R0701 0662057A73 10K
R0702 0662057A73 10K
R0703 0662057A73 10K
R0704 0662057A73 10K
R0705 0662057A41 470
R0706 0662057A89 47K
R0707 0662057A81 22K
R0708 0662057A65 4.7K
R0709 0662057A65 4.7K
R0710 0662057A65 4.7K
R0711 0662057A65 4.7K
R0712 0662057A73 10K
R0713 0662057A53 1.5K
R0715 0662057A97 100K
R0716 0662057A97 100K
INTEGRATED CIRCUITS:
U0651 5102109U01 LCD Segments driver
U0652 5113818A03 High Performance
U0653 5102110U03 IC UP OTP Prog. RCH C
U0654 5113816A07 Reg. 5V Pos.500MA
MC78M05BD
U0655 5113805A84 IC Mux/Demux Dual 4-ch
analog
U0656 5113805A84 IC Mux/Demux Dual 4-ch
analog
FILTERS:
Y0650 4880065M01 4.00 MHZ
NON REFERENCED ITEMS
8405410Z01 or
8402112U01
BOARD P.W.
a. Not used on 8402112U01
