December 6, 2004 68P81083C20-D
3-2 Test Equipment, Service Aids and Tools: Service Aids and Recommended Tools
Service Aids and Recommended Tools
Refer to the “SERVICE AIDS” and “RECOMMENDED TOOLS LIST” for a listing and description of
the service aids and tools designed specifically for servicing the radio, as well as the more common
tools required to disassemble and properly maintain the radio. These kits and/or parts are available
from Motorola.
The following table lists service aids recommended for working on the radio. While all of these items
are available from Motorola, most are standard shop equipment items, and any equivalent item
capable of the same performance may be substituted for the item listed.
Field Programming
The radio can be aligned and programmed in the field. This requires specific equipment and special
instructions. Refer to the “Radio Service Software User’s Manual” for complete field programming information..
Table 3-2. Service Aids
Part Number Description Application
RKN4062B Programming and Cloning
Cable
Connects the RIB RLN4008B to the microphone connector. Cloning
is the act of transferring programmed data from one radio to another.
RKN4063A FLASH, Programming and
Cloning Cable with Test Box
Connects the RIB RLN4008B to the accessory connector. Cloning is
the act of transferring programmed data from one radio to another.
FLASHing is the act of adding new software to the radio.
3080376E36 Control Head Extender Cable Connects the control head to the 18 pin connector.
(see page 4 for correct use of this cable).
GTF373A* Test Box Cable Connects radio to GTF180B test box.
GTF372A* Combined Interface Cable Connects radio to RLN4008B RIB and Microphone Port and Acces-
sory Connector.
HKN4191A DC Power Cable for radios Interconnects radio below 50 W to power supply.
HKN6110 DC Power Cable for radios Interconnects radio of over 50 W to power supply.
RLN4460A or
GTF180B*
Test Box Allows switching for radio testing.
RLN4008B Radio Interface Box Enables communications between the radio and the computer’s
serial communications adapter.
0180358A56 or
EPN4041A*
Power Supply Used to supply power to the RIB (220 VAC).
0180357A57 Power Supply Used to supply power to the RIB (110 VAC).
EPN4040A* Power Supply Used to supply power to the RIB (240 VAC).
3080369B71 or
3080369B72
Computer Interface Cable Use B72 for the IBM PC AT. All other IBM models use B71. Connects
the computer’s serial communications adapter to the RIB.
RLN4438A Adapter 25 pin (F) to 9 pin (M) adapter, for use with 3080369B72 for AT appli-
cations.
RLN1015B Smart Radio Interface Box
(SRIB)
Enables communications between the radio and the computer’s
serial communications adapter. For FLASHing, programming and
cloning.
0180302E27 SRIB Power Supply Used to supply power to the SRIB (120 VAC).
2580373E86 SRIB Power Supply Used to supply power to the SRIB (220 VAC).
RLN4488A SRIB Battery Pack Used to power the SRIB from a battery.
3080390B48 or
3080390B49
Computer Interface Cable Use B49 for the IBM PC AT. All other IBM models use B48. Connects
the computer’s serial communications adapter to the SRIB only.
