Chapter 10: Digrams and Parts Lists 10-16
68P81083C20-D December 6, 2004
Control Head Model II Parts List
Reference
Symbol
MOTOROLA
Part Number Description
CAPACITORS, Fixed:
unless otherwise stated
C0650 2113743A23 .220uF
C0651 2311049J23 10uF
C0652 2113741F49 .01uF
C0653 2113741F17 470pF
C0654 2113741F17 470pF
C0655 2113741F17 470pF
C0656 2113741F17 470pF
C0657 2113741F17 470pF
C0658 2113741F17 470pF
C0659 2113741F17 470pF
C0660 2113741F17 470pF
C0661 2113741F17 470pF
C0662 2113741F17 470pF
C0663 2113741F17 470pF
C0664 2113740F37 27pF
C0665 2113740F37 27pF
C0666 2113743K15 .1uF
C0667 2311049J12 4.7uF
C0668 2113743K15 .1uF
C0669 2113743K15 .1uF
C0670 2311049J23 10uF
C0671 2311049J12 4.7uF
C0672 2311049J12 4.7uF
C0673 2311049J12 4.7uF
C0674 2113741F17 470pF
C0675 2113741F17 470pF
C0676 2113741F17 470pF
C0677 2113741F17 470pF
C0678 2113741F17 470pF
C0679 2113741F17 470pF
C0680 2113741F17 470pF
C0681 2113743K15 .1uF
C0683 2113743K15 .1uF
C0684 2113740F15 3.3pF
C0685 2113741F49 0.01uF
C0686 2113741F25 1nF
C0687 2311049J12 4.7uF
C0688 2113741F49 0.01uF
C0689 2113741F49 0.01uF
C0699 2113743F08 .22uF
C0690 231149A95 10uF
DIODES:
D0659 4813830A15 5.6V
D0660 4813830A15 5.6V
D0661 4813830A33 20V
D0664 4813830A15 5.6V
D0665 4813830A15 5.6V
D0666 4813830A15 5.6V
D0667 4813830A15 5.6V
D0668 4813830A15 5.6V
D0669 4813830A15 5.6V
D0721 4813830A15 5.6V
D0722 4813830A15 5.6V
D0730 4805129M12 Diode
DISPLAY:
H0650 7202076U04 DSTN-LCD GLAS
CONNECTORS:
J0650 2805922V01 PLUG VERT
P0651 2805924V01 CONNECTOR MIC
INDUCTORS:
L0650 2462587T30 1000nH
L0651 2462587K26 33000 nH
TRANSISTORS:
Q0650 4813824A17 PNP
Q0651 4813824A10 NPN
Q0652 4813824A10 NPN
Q0653 4813824A17 PNP
Q0654 4813824A10 NPN
Q0655 4813824A10 NPN
Q0656 4813824A07 NPN
Q0657 4813824A10 NPN
Q0658 4813824A10 NPN
Q0659 4813824A10 NPN
Q0660 4813824A10 NPN
Q0661 4813824A17 PNP
Q0662 4813824A17 PNP
Q0663 4813824A10 NPN
Q0664 4813822A08 PNP
Q0665 4813824A10 NPN
Q0666 4813824A10 NPN
Reference
Symbol
MOTOROLA
Part Number Description
Q0667 4813822A08 PNP
RESISTORS:
R0650 0662057A01 10
R0651 0662057A01 10
R0652 0662057A53 1.5K
R0653 0662057A53 1.5K
R0658 0662057A73 10K
R0659 0662057A73 10K
R0660 0662057A73 10K
R0661 0662057A73 10K
R0662 0662057A73 10K
R0663 0662057A01 10
R0665 0662057B47 0
R0666 0662057A73 10K
R0667 0662057A73 10K
R0669 0662057A73 10K
R0670 0662057A73 10K
R0671 0662057A73 10K
R0672 0662057A73 10K
R0673 0662057A73 10K
R0674 0662057A73 10K
R0675 0662057A73 10K
R0676 0662057A65 4.7K
R0677 0662057A56 2K
R0678 0662057A73 10K
R0679 0662057A65 4.7K
R0680 0662057A73 10K
R0681 0662057A81 22K
R0682 0662057A73 10K
R0683 0662057A89 47K
R0684 0662057A65 4.7K
R0685 0662057A97 100K
R0687 0662057A57 2.2K
R0688 0662057A73 10K
R0688 0662057A73 10K
R0689 0662057A65 4.7K
R0690 0662057A97 100K
R0691 0662057A89 47K
R0692 0662057A65 4.7K
R0693 0662057A65 4.7K
R0694 0662057A65 4.7K
R0695 0662057A73 10K
R0696 1805911V01 POT VOL
Reference
Symbol
MOTOROLA
Part Number Description
R0697 1802100U01 POTM 5K
R0698 0662057B16 560K
R0699 0662057B16 560K
R0700 0662057A73 10K
R0703 0662057A37 330
R0704 0662057A41 470
R0705 0662057A41 470
R0706 0662057A41 470
R0707 0662057A69 6.8K
R0708 0662057A69 6.8K
R0709 0662057A69 6.8K
R0710 0662057A69 6.8K
R0711 0662057A69 6.8K
R0712 0662057A77 15K
R0713 0662057A77 15K
R0714 0662057G07 75K
R0715 0662057B16 560K
R0716 0662057A73 10K
R0717 0662057A73 10K
R0718 0662057A97 100K
R0719 0662057A73 10K
R0720 0662057A73 10K
R0721 0662057A57 2.2K
R0722 0662057A73 10K
R0723 0662057A65 4.7K
R0724 0662057A73 10K
R0725 0662057A65 4.7K
R0726 0662057A73 10K
R0727 0662057A57 2.2K
R0728 0662057A89 47K
R0729 0662057A41 470
R0730 0662057A73 10K
R0731 0662057A73 10K
R0732 0680194M18 51
R0733 0662057A65 4.7K
R0734 0662057A37 330
R0735 0662057G07 75K
R0736 0662057R60 10K .1W 1%
R0737 0662057A73 10K
R0738 0662057R02 10 .1W 1%
R0739 0662057R02 10 .1W 1%
R0740 0662057A73 10K
R0741 0662057G13 100K
R0742 0680149M02 100K THERMISTOR
Reference
Symbol
MOTOROLA
Part Number Description
To Next Page
