10-23 Chapter 10: Digrams and Parts Lists
December 6, 2004 68P81083C20-D
For optimum performance, order replacement diodes,
transistors and circuit modules by Motorola part number
only.
• When ordering crystals, specify carrier frequency,
crystal frequency, crystal type number and Motorola
part number.
• Part value notations: p=10
-12
, n=10
-9
, µ=10
-6
,
m=10
-3
, k=10
3
, M=10
6
R0744 0662057A61 3.3K
R0746 0662057R60 10K .1W 1%
R0747 0662057A49 1K
R0748 0662057A49 1K
R0749 0662057B05 200K
R0750 0662057B05 200K
R0751 0662057A97 100K
R0752 0662057G13 100K
R0753 0662057G13 100K
INTERGRATED CIRCUITS:
U0650 5113816A07 REG 5V POS 500MA
U0651 5102101U01 LCD Controller
U0652 5102102U01 LCD Driver
U0653 5102100U03 Microcontroller
U0654 5113805A60 OCT D W/COM CLKRS
HC273
U0655 5105461G54 DC/DC Converter 14Pin SOP
U0656 5113818A03 High Performance Singl.
SPLY
U0657 5113805A84 MUX/DEMUX Dual 4-ch ana-
log
U0658 5113805A84 MUX/DEMUX Dual 4-ch ana-
log
U0659 5113805A84 MUX/DEMUX Dual 4-ch ana-
log
U0660 5113815A02 Undervoltage Sensing Ckt.
FILTERS:
Y0650 4802100U01 4.000 MHz
NON REFERENCED ITEMS
0702084U01 Frame
1302085U01 Bezel LCD
2802102U01 Connector elastomeric
8405412Z01 Board P.W.
Reference
Symbol
MOTOROLA
Part Number Description
