Chapter 10: Digrams and Parts Lists 10-54
68P81083C20-D December 6, 2004
For optimum performance, order replacement diodes, transis-
tors, and circuit modules by Motorola part number only.
1. When ordering crystals, specify carrier frequency, crystal fre-
quency, crystal type number, and Motorola part number.
2. Part value notations: p=10
-12
,
n=10
-9
,
µ=10
-6
, m=10
-3
,
k=10
3
,M=10
6
R0514 0662057B02 150K
R0518 0662057A65 4.7K
R0519 0662057A81 22K
R0521 0662057A81 22K
R0522 0662057A81 22K
R0523 0662057A73 10K
R0525 0662057A65 4.7K
R0526 0662057A73 10K
R0527 0662057A73 10K
R0529 0662057B47 0
R0535 0662057A65 4.7K
R0546 0662057B47 0
R0547 0662057R92 0
R0548 0662057C01 0
R0549 0662057G33 237k
R0550 0662057A89 0
R0552 0662057A97 0
R0553 0662057A97 0
R0554 0662057A97 0
R0556 0662057A25 100k
R0557 0662057R60 10K
R0558 0660076E83 27K
R0559 0662057R55 7.5K
R0560 0660076E83 27K
R0563 0662057A51 1.2k
R0564 0662057A57 0
R0566 0662057A73 10K
R0567 0662057R92 47K
R0568 0662057A65 4.7K
R0569 0662057R92 47K
R0570 0662057A49 1K
R0571 0662057A25 0
R0572 0662057A73 0
R0573 0662057A49 0
R0576 0662057R92 47K
R0577 0662057A97 0
R0578 0662057A65 4.7K
R0579 0662057A65 4.7K
R0580 0662057A65 4.7K
R0581 0662057A65 0
R0582 0662057R92 47K
R0583 0662057R92 0
R0585 0662057A49 0
R0586 0662057A49 1.0K
Reference
Symbol
MOTOROLA
Part Number Description
R0587 0662057A75 12k
R0589 0662057G33 237k
R0598 0662057C01 0
Integrated Circuits:
U0101 5185748L01 32k x 8 sram
U0103 5113802A75 Microprocessor
U0104 5185765B30 Support Logic IC
U0105 5113806A20 MUX/DEMUX Triple 2-
Chan
U0106 5105625U22 FLASH 1Mx8
U0108 5105109Z72 32k x 8 EEPROM ‘TSOP’
U0200 5185765B33 ASFIC
U0201 5183222M49 OP AMP
U0202 5183222M49 OP AMP
U0203 5109699X01 Audio Pwr Amp
U0400 5184704M61 Analog Switch
U0401 5113818A03 OP Ampl
U0500 5105625U96 5v Reg
U0501 5105625U97 9.3v Reg
U0502 5113816A04 8V Regulator
U0510 5105625U26 Dual 555 Timer
U0550 5183222M49 Opnl Ampl
U0551 5113811G02 D/A Converter
Diodes, Zener:
VR0001 4813830A14 5.1V
VR0100 4813830A27 14V
VR0405 4813830A15 5.6V
VR0406 4813830A27 14V
VR0407 4813830A27 14V
VR0409 4813830A27 14V
VR0410 4813830A27 14V
VR0413 4813830A15 5.6V
VR0414 4813830A15 5.6V
VR0415 4813830A15 5.6V
VR0418 4813830A27 14V
VR0419 4813830A23 10V
VR0420 4813830A23 10V
VR0421 4813830A23 10V
VR0422 4813830A23 10V
VR0424 4813830A27 14V
VR0425 4813830A40 33V
VR0426 4813830A27 14V
Reference
Symbol
MOTOROLA
Part Number Description
VR0427 4813830A27 14V
VR0428 4813830A23 10V
VR0429 4813830A27 14V
VR0430 4813830A27 14V
VR0431 4813830A15 5.6V
VR0511 4813830A27 14V
a. If 50x80 Pads (newer models) use 0662057C61 270.
b. If (*) use 0662057A57 2.7 K.
Reference
Symbol
MOTOROLA
Part Number Description
To Next Page
