Motorola MOTOTRBO XPR 7550e - GOB Board Parts List (PC000957 A01_CA)

9-16 Circuit Board/Schematic Diagrams and Parts List for Interface, Keypad and GOB Board
GOB Board Parts List (PC000957A01_CA)
Circuit
Ref
Motorola
Part No.
C5100 2113946S35
C5101 2113945A05
C5102 2113946S35
C5103 2113945Y02
C5104 2113945D01
C5105 2113945A11
C5106 2113945D01
C5107 2113956B21
C5108 2113956B21
C5109 2113945L49
C5110 2113945A11
C5111 2113945D01
C5112 2113945Y02
C5113 2113956B21
C5114 2113956B21
C5115 2113945Y02
C5116 2113945D01
C5117 2113945D01
C5118 2113945Y02
C5119 2113956B21
C5120
2113946B04
C5121 21667009168
C5125 2113945Y02
C5126 21667009326
C5127 21667009326
C5128 2113945Y02
C5129 2113945Y02
C5130 2113945Y02
C5131 2113945Y02
C5132 2113945A05
C5134 2113945Y02
C5135 2113945Y02
C5136 2113945Y02
C5139 2113945Y02
C5140 2113945Y02
C5200 2113945Y02
C5201 2113945Y02
C6000 21667009156
C6001 21667009166
C6002 2113945A11
C6003 21667009156
C6004 21667009166
C6005 2113945A11
C6006 2113945A11
C6007 21667009166
C6008 21667009156
R5104 0613952G67
R5105 0613952R01
R5106 0613952R01
R5110 0613952R01
R5112 0613952R25
R5113 0613952R25
R5114 0613952R25
R5122 0613952Q25
R5123 0613952Q25
R5124 0613952R01
R5125 0613952R01
R5128 NOTPLACED
R5129 NOTPLACED
R5130 0613952R01
R5131 0613952R01
R5133 0613952G67
R5134
0613952R01
R5135
NOTPLACED
R5136 0613952R01
R5137 0613952R66
R5138
NOTPLACED
R5140 0613952R01
R5141 0613952R01
R5200
NOTPLACED
R5201 0613952R01
R5202
NOTPLACED
R5203
NOTPLACED
R5204 0613952R01
R5206 0613952K58
R5207 0613952K58
R5208 0613952R01
R5300 0613952Q33
Circuit
Ref
Motorola
Part No.
R5301 0613952Q33
R5302 0613952Q33
R5303 0613952Q73
R6001 0613952R01
R6002 0613952P01
R6003 0613952P01
R6004 0613952R66
R6005 0613952R66
R6006 0613952R01
R6200
0613952R25
R9001 NOTPLACED
