Motorola MOTOTRBO XPR 7550e - Page 90

6-30 Circuit Board/Schematic Diagrams and Parts List for UHF
C0704 21012193001
C0705 21012193001
C0706 2113946U01
C0707 2113946U01
C0708 21667009166
C0709 NOTPLACED
C0710 21667009370
C0711 NOTPLACED
C0712 21667009416
C0713 21667009166
C0714 NOTPLACED
C0715 21667009374
C0716 21667009368
C0718 2113945A05
C0719 NOTPLACED
C0720 2113944C49
C0721 NOTPLACED
C0722 NOTPLACED
C0723 CA000442A01
C0724 NOTPLACED
C0725 2171846M10
C0726 2171846M12
C0727 2171846M09
C0728 21667009163
C0730 2175390H01
C0732 2113945A05
C0733 NOTPLACED
C0734 CA000438A01
Circuit
Ref.
Motorola
Part No.
C0735 21667009383
C0738 21012193001
C0739 NOTPLACED
C0740 NOTPLACED
C0741 21667009156
C0742 2113945B04
C0743 2113945A09
C0744 2113945A02
C0745 2113946K02
C0747 NOTPLACED
C0748 NOTPLACED
C0801 21667009332
C0802 21667009288
C0803 21667009366
C0804 21667009332
C0805 21667009163
C0806 21667009284
C0811 21012193001
C0812 NOTPLACED
C0813 2113945Y02
C0814 21012193001
C0816 2171846M08
C0817 NOTPLACED
C0819 2113945Y02
C0900 21012150001
C0901 21667009166
C0902 21667009166
C0903 21012193001
Circuit
Ref.
Motorola
Part No.
C0904 2113945B04
C0905 NOTPLACED
C0906 21012193001
C0907 2113945B04
C0908 21012193001
C0909 2113945B04
C0910 2113946K02
C0911 21667009166
C1000 2113946B06
C1001 2113946B04
C1002 2113945F07
C1003 2113945F07
C1004 2113946B04
C1005 2113946B04
C1006 2113956B54
C1007 2113946B04
C1008 2113946B04
C1009 21667013156
C1011 21012193001
C1080 2113945F07
C1081 NOTPLACED
C1082 2113946B04
C1083 2113946B04
C1101 2113946B06
C1102 2113946B06
C1103 2113946B06
C1104 2113946B06
C1105 2113946B06
Circuit
Ref.
Motorola
Part No.
C1106 21012193001
C1107 21012193001
C1108 21012193001
C1109 21012193001
C1110 21012193001
C1111 NOTPLACED
C1113 NOTPLACED
C1120 NOTPLACED
C1121 NOTPLACED
C1122 2113946B06
C1123 2113946B06
C1124 2113946B06
C1125 2113946B06
C1126 2113946B06
C1127 21012193001
C1128 21012193001
C1129 21012193001
C1130 21012193001
C1131 21012193001
C1132 21012193001
C1133 21012193001
C1140 NOTPLACED
C1141 NOTPLACED
C1142 2113946B06
C1143 2113946B06
C1144 21012193001
C1145 21012193001
C1146 21012193001
Circuit
Ref.
Motorola
Part No.
