Motorola Symbol DS9808 - Maxicode; QR Code

Motorola Symbol DS9808

352 pages

To Next Page

To Next Page

To Previous Page

To Previous Page

Loading...

Symbologies 10 - 71

Maxicode

Parameter # F0h, 26h

To enable or disable Maxicode, scan the appropriate bar code below.

QR Code

Parameter # F0h,25h

To enable or disable QR Code, scan the appropriate bar code below.

Enable Maxicode

(01h)

*Disable Maxicode

(00h)

*Enable QR Code

(01h)

Disable QR Code

(00h)
