Maintenance & Technical Specifications 3 - 5
Technical Specifications
Table 3-2
Technical Specifications
Item Description
Physical Characteristics
Dimensions 8 in. (max) H x 5.4 in. L x 3.4 in. W
20.3 cm (max) H x 13.7 cm L x 8.6 cm W
Weight 12 oz. (340 g)
Power
With optional RFID module
5 +/-10%VDC @ 450 mA nominal
5 +/-10%VDC @ 1.2 A nominal (special power supply and cable required)
Performance Characteristics: DS9808-SR/DL and DS9808-LR/LL Imager Engine
Light Source Aiming pattern: 650 nm laser diode
Illumination: 630 nm LED
Imager Field of View
(Vertical x Horizontal)
39º (H) x 25º (V)
Roll
Pitch
Yaw
360º
+/- 65º
+/- 60º
Swipe Speed Programmable up to 100 in. (254 cm) per second
Performance Characteristics: DS9808-LR/LL Laser Engine
Light Source 650nm laser diode
Scan Angle 40º nominal
Symbology Decode Capability
1D UPC/EAN, UPC/EAN with supplementals, Bookland EAN, ISSN, UCC Coupon
Extended Code, Code 128, GS1-128, ISBT 128, Code 39, Code 39 Full ASCII,
Trioptic Code 39, Code 32, Code 93, Code 11, Matrix 2 of 5, Interleaved 2 of 5,
Discrete 2 of 5, Codabar, MSI, Chinese 2 of 5, GS1 DataBar variants
2D PDF417, MicroPDF417, Composite Codes, TLC-39, Data Matrix, Maxicode,
QR Code, MicroQR, Aztec
Postal US Postnet and Planet, UK Postal, Japan, Australian, Netherlands KIX Code,
USPS 4CB/One Code/Intelligent Mail, UPU FICS Postal
Typical Working Distance See
Decode Ranges on page 2-8
.
Motion Tolerances Swipe speed: 100 inches per second at full illumination, measured on
100% UPC bar code 80% MRD at 4 inches distance form the housing
