Imaging Preferences 5 - 13

Image Enhancement

Parameter # F1h, 34h

This parameter configures the digital scanner's Image Enhance feature. This feature uses a combination of edge

sharpening and contrast enhancement to produce an image that is visually pleasing.

The levels of image enhancement are:

•

Off (0) - Default

•

Low (1)

•

Med (2)

•

High (3).

*Off

(0)

Low

(1)

Medium

(2)

High

(3)
