Motorola V3 Service Manual

6809497A15-A January 31, 2006 17
Level 1 and 2 Service Manual Tools and Test Equipment
Tools and Test Equipment
Table 1 lists tools and test equipment recommended for disassembly and reassembly
of V3x telephones. Use either the listed items or equivalents.
Table 1. General Test Equipment and Tools
Motorola Part Number
1
Description Application
RSX4043-A Torque Driver Used to remove and replace screws.
—
Torque Driver Bit T-3, T-5, T-6 Plus, Apex
440-6IP Torx Plus or equivalent
Used with torque driver.
See Table 7 Rapid Charger
Used to charge battery and to power
phone.
0180386A82
Antistatic Mat Kit (includes 66-80387A95
antistatic mat, 66-80334B36 ground
cord, and 42-80385A59 wrist band)
Provides protection from damage to
device caused by electrostatic discharge
(ESD).
0-00-00-30005
Disassembly tool, plastic with flat and
pointed ends (manual opening tool)
Used during assembly/disassembly of
phone.
— Tweezers, Plastic
Used during assembly/disassembly of
phone.
— Digital Multimeter, HP34401A
2
Used to measure battery voltage.
8102430Z04 GSM / DCS Test SIM Used to enable manual test mode.
1. To order in North America, contact Motorola Aftermarket and Accessories Division (AAD) at (800) 422-4210 or
FAX (800) 622-6210; Internationally, AAD can be reached by calling (847) 538-8023 or faxing (847) 576-3023.
2. Not available from Motorola. To order, contact Hewlett Packard at (800) 452-4844.
1 and 2
V3x
6809497A15-A

Motorola V3 Specifications

General

FM radio	No
Ringer type	Polyphonic
Polyphonic rings quantity	40
Rear camera resolution	640 x 480 pixels
Interface	CE Bus, USB / Bluetooth
Networking type	GSM
Playback formats	MIDI, MP3
Operating frequency	GSM 850 / GSM 900 / GSM 1800 / GSM 1900 MHz
Internal memory	5.5 MB
Compatible memory cards	Not supported
Type	-
Product color	Aluminum
Form factor	Flip
Personal info management (PIM)	Games, Calendar, To-do list
Multimedia Messaging Service (MMS)	Multimedia Messaging Service (MMS) is a standard way to send messages that include multimedia content to and from a mobile phone over a cellular network
Battery type	Li-Ion
Talk time (2G)	3 h
Battery capacity	680 mAh
Standby time (2G)	200 h
Display type	TFT
Display diagonal	2.2 \
External display	CSTN
Display resolution	176 x 220 pixels
Display number of colors	65536 colors
External display resolution	96 x 80 pixels
WAP	2.0
Data network	GPRS
SIM card type	MiniSIM
SIM card capability	Single SIM
USB connector type	Mini-USB
Video compression formats	MPEG4

Weight and Dimensions

Depth	13.9 mm
Width	53 mm
Height	98 mm
Weight	95 g
