Level 1 and 2 Service Manual Disassembly
Removing and Replacing the Keypad, Volume/Smart, and Voice Keys
1. Remove battery cover, battery, SIM, antenna, rear housing, and transceiver
board assembly as described in the procedures.
2. Use the plastic tweezers to lift the volume/smart keys out of their slot in the
front housing (see Figure 14).
051223o
Figure 13. Removing the Keypad, Volume/Smart, and Voice Buttons
Plastic tweezers
Volume/Smart Keys
