6809497A15-A January 31, 2006 9
Level 1 and 2 Service Manual Introduction
Specifications
Table 1. Specifications
Function Specification
Frequency Range EGSM TX: 880 - 915 MHz
Frequency (MHz) = 890 + (0.2 × n) where: 0 ≤ n ≤ 124
Frequency (MHz) = 890 + (0.2 × (n – 1024)) where: 955 ≤ n ≤ 1023
RX: 925 – 960 MHz
Frequency (MHz) = 935 + (0.2 × n) where: 0 ≤ n ≤ 124
Frequency (MHz) = 935 + (0.2 × (n – 1024)) where: 955 ≤ n ≤ 1023
Frequency Range DCS TX: 1710 to 1785 MHz
Frequency (MHz) = 1710.2 + (0.2 × (n – 512)) where: 512 ≤ n ≤ 885
RX: 1805.2 to 1879.8 MHz
Frequency (MHz) = 1805.2 + (0.2 × (n – 512)) where: 512 ≤ n ≤ 885
Frequency Range PCS TX: 1850 to 1910 MHz
Frequency (MHz) = 1850.2 + (0.2 × (n – 512)) where: 512 ≤ n ≤ 810
RX: 1930 to 1990 MHz
Frequency (MHz) = 1930.2 + (0.2 × (n – 512)) where: 512 ≤ n ≤ 810
Frequency Range UMTS TX: 1920 to 1980 MHz
Frequency (MHz) = UARFCN
1
÷ 5, where: 9612 < UARFCN
1
< 9888
UARFCN
1
in increments of 25
RX: 2110 to 2170 MHz
Frequency (MHz) = UARFCN
1
÷ 5, where: 10562 < UARFCN
1
< 10838
UARFCN
1
in increments of 25
Channel Spacing 200 kHz (GSM, DCS, PCS), 5 MHz UMTS
Channels 174 EGSM, 374 DCS, 274 PCS carriers with 8 channels per carrier, 11 UMTS
Duplex Spacing 45 MHz GSM, 95 MHz DCS, 80 MHz PCS, 190 MHz UMTS
Modulation GMSK AT BT = 0.3 (GSM, DCS, PCS), QPSK (UMTS)
Transmitter Phase Accuracy 5 degrees RMS, 20 Degrees peak
Frequency Error +
0.1ppm
Input/Output Impedance 50 ohms (nominal)
Nominal Operating Voltage 3.6 Vdc +
10% (battery)
+4.4 Vdc +
10% (external connector)
Size 89 cc
Weight 118 g
Display Main Display: 262K color TFT, 320 x 240, 2.2”
CLI Display: 65K color STN, 96x80, 1”
Battery Life (840mAh)
2
GSM: Talk time: Up to 215 minutes
GSM: Standby time: Up to 220 to 260 hours
WCDMA Talk time: 131 hours
WCDMA Standby time: 227 hours
WCDMA Video talk time: Up to 90 minutes
Nominal Operating
Temperature Range
-10º C to +55º C
