Motorola V3 Service Manual

10 January 31, 2006 6809497A15-A
Introduction V3x
GSM System Functions Specification
Speech Coding Type Regular Pulse excitation / linear predictive coding with long term prediction
(RPE LPC with LTP)
Bit Rate 13.0 kbps
RF Power Output 32 dBm nominal GSM, 28.5 dBm nominal DCS / PCS
Spurious Emissions -36 dBm from 0.1 to 1 GHz, -30 dBm from 1 to 4 GHz
Receive Sensitivity -102 dBm GSM, -102 dBm DCS / PCS
RX Bit Error Rate < 2%
UMTS System Functions Specification
Speech Coding Type Adaptive Multirate (AMR)
RF Power Output 21 dBm
Spurious Emissions -36 dBm from 0.1 to 1 GHz, -30 dBm from 1 to 4 GHz
Error Vector Magnitude < 17.5%
PN9 Bit Error Rate (VER) 0.1% @12.2K, -106.7 dBm
ACLR -33 dBm @+
5 MHz, -43 dBm @+10 MHz

Motorola V3 Specifications

General

FM radio	No
Ringer type	Polyphonic
Polyphonic rings quantity	40
Rear camera resolution	640 x 480 pixels
Interface	CE Bus, USB / Bluetooth
Networking type	GSM
Playback formats	MIDI, MP3
Operating frequency	GSM 850 / GSM 900 / GSM 1800 / GSM 1900 MHz
Internal memory	5.5 MB
Compatible memory cards	Not supported
Type	-
Product color	Aluminum
Form factor	Flip
Personal info management (PIM)	Games, Calendar, To-do list
Multimedia Messaging Service (MMS)	Multimedia Messaging Service (MMS) is a standard way to send messages that include multimedia content to and from a mobile phone over a cellular network
Battery type	Li-Ion
Talk time (2G)	3 h
Battery capacity	680 mAh
Standby time (2G)	200 h
Display type	TFT
Display diagonal	2.2 \
External display	CSTN
Display resolution	176 x 220 pixels
Display number of colors	65536 colors
External display resolution	96 x 80 pixels
WAP	2.0
Data network	GPRS
SIM card type	MiniSIM
SIM card capability	Single SIM
USB connector type	Mini-USB
Video compression formats	MPEG4

Weight and Dimensions

Depth	13.9 mm
Width	53 mm
Height	98 mm
Weight	95 g
