Motorola V3 Service Manual

6809497A15-A January 31, 2006 47
Level 1 and 2 Service Manual Part Numbers
Exploded View Parts List
To order parts use the following Link:
https://wissc.motorola.com/wissc_root/main/BrowserOK.html
(Password is Required)
For information on ordering parts contact EMEA at +49 461 803 1404.
Table 4. Exploded View Parts List
Item
Number
Part Number Description
Item
Number
Part Number Description
1 6171885B01 LENS, 2MP 20 0171343C01 MODULE, VGA
2 4885102C24 FLASH, CAMERA
21 3271688B02 GASKET, VGA
3 6188777Y01 LENS, CLI 22 6171865B01 LENS, VGA
4 0171425C01 HOUSING, FLIP OUTER 23 6188778Y01 LENS, MAIN DISPLAY
5 3371139D01 ESCUTCHEON, FLIP
24 0387726M02 SCREW, FLIP
6 1171902B01 GASKET, CLI
25 0188747Y01
HOUSING, BASE INNER
ASSY
7 0171102C01 MODULE, DISPLAY
26 3971966B01 CONTACT, KNUCKLE
8 0171456C01 FLEX, HINGE
27 3888722Y01 KEYPAD, MAIN
9 5571967B01 CAM, HINGE
28 3871943B01
BUTTONS, SIDE, UP / DN /
SMART
10 3871407C01 ADJUST, MACRO
29 3871942B01 BUTTONS, SIDE, CAM / VA
11 0171347C01 MODULE, 2MP
30 0171646C01 FLEX, POPPLE DOME / EL
12 3271688B01 GASKET, 2MP 31 0171107C01 SHIELD, SPACER ASSY
13 5988515L01 MAGNET 32 SLG4932AA PCB, TRANSCEIVER, ASSY
14 0171325C01 SPEAKER, EARPIECE ASSY
33 0188746Y01
HOUSING, BASE OUTER
ASSY
15 0188755Y01 HOUSING, FLIP INNER
34 0387791L07 SCREW, BASE (6X)
16 1371698B01 MESH, ACOUSTIC 35 SNN5781A BATTERY, MAIN, SC5
17 0387726M02 SCREW, FLIP (4X)
36 1571931B01 COVER, BATTERY SC5
18
3271689B02
3271689B01
BUMPER, FLIP (left)
Bumper, flip (right)
37 1571951B01
HOUSING, LOWER ANTENNA
CAP
19 3371697B02 ESCUTCHEON, EARPIECE
E
There is a danger of explosion if the Lithium Ion battery pack is replaced incorrectly.
Replace only with the same type of battery or equivalent as recommended by the
battery manufacturer. Dispose of used batteries according to the manufacturer’s
instructions.

Motorola V3 Specifications

General

FM radio	No
Ringer type	Polyphonic
Polyphonic rings quantity	40
Rear camera resolution	640 x 480 pixels
Interface	CE Bus, USB / Bluetooth
Networking type	GSM
Playback formats	MIDI, MP3
Operating frequency	GSM 850 / GSM 900 / GSM 1800 / GSM 1900 MHz
Internal memory	5.5 MB
Compatible memory cards	Not supported
Type	-
Product color	Aluminum
Form factor	Flip
Personal info management (PIM)	Games, Calendar, To-do list
Multimedia Messaging Service (MMS)	Multimedia Messaging Service (MMS) is a standard way to send messages that include multimedia content to and from a mobile phone over a cellular network
Battery type	Li-Ion
Talk time (2G)	3 h
Battery capacity	680 mAh
Standby time (2G)	200 h
Display type	TFT
Display diagonal	2.2 \
External display	CSTN
Display resolution	176 x 220 pixels
Display number of colors	65536 colors
External display resolution	96 x 80 pixels
WAP	2.0
Data network	GPRS
SIM card type	MiniSIM
SIM card capability	Single SIM
USB connector type	Mini-USB
Video compression formats	MPEG4

Weight and Dimensions

Depth	13.9 mm
Width	53 mm
Height	98 mm
Weight	95 g
