Disassembly/Reassembly Procedures Radio Exploded Mechanical Views and Parts Lists 5-45
Table 5-5. Additional Part List Table
Front Kit -
VHF/8/900
MHz
Front Cover Kit, Roman Keypad, GNSS PMLN7238_
Front Cover Kit, Roman Keypad, GNSS (Yellow) PMLN7515_
Front Cover Kit, NKP PMLN7323_
Front Cover Kit, NKP, GNSS PMLN7239_
Front Cover Kit, NKP, GNSS (Yellow) PMLN7514_
Front Kit - UHF
Front Cover Kit, Roman Keypad, GNSS PMLN7425_
Front Cover Kit, Roman Keypad, GNSS (Yellow) PMLN7515_
Front Cover Kit, NKP PMLN7323_
Front Cover Kit, NKP, GNSS PMLN7239_
Front Cover Kit, NKP, GNSS (Yellow) PMLN7514_
Front Housing
Assembly
Front Housing Assembly FKP, English 0104065J42
Front Housing Assembly NKP 0104065J43
Back Kits*
VHF
BC Kit, 136–174 MHz, 5W, FKP with GNSS PMLD4727_S
BC Kit, 136–174 MHz, 5W, FKP PMLD4776_S
BC Kit, 136–174 MHz, 5W, MOTOTRBO NKP with GNSS PMLD4729_S
UHF
BC Kit, 403–527 MHz, 4W, MOTOTRBO FKP with GNSS PMLE5064_S
BC Kit, 403–527 MHz, 4W, MOTOTRBO NKP with GNSS PMLE5066_S
800/900 MHz
BC Kit, 806–941 MHz, 2.5W, FKP, GNSS, BT, WiFi PMLF4158_S
BC Kit, 806–941 MHz, 2.5W, NKP, GNSS, BT, WiFi PMLF4160_S
Option Board
Kit
Generic Option Board Kit PMLN7324_S
Keypad Flex
Assy Flex, Mainboard to Keypad Board (VHF & 8/900
MHz)
0104065J46
PCBA Flex Assembly, 3 Layer (UHF, 300 MHz & 350 MHz) PA001338A01
Nameplate
XPR 7350e Nameplate 33012015038
XPR 7550e Nameplate 33012015039
XPR 7380e Nameplate 33012015040
XPR 7580e Nameplate 33012015041
