3-4 Transceiver Performance Testing Display Model Test Mode
3.3 Display Model Test Mode
3.3.1 Entering Display Radio Test Mode
1. Turn the radio on.
2. Within 10 seconds after Self Test is complete, press Side Button 2 five times in succession
3. The radio beeps and will show a series of displays that will give information regarding various
version numbers and subscriber specific information. The displays are described in Table 3-2.
3.3.2 LCD Flicker Test Mode
1. Press and hold side button 1 to access the flicker test. A black screen will appear on the
display.
2. The screen will remain black for a properly functioning display.
3. If there is any flickering, send to the service depot to be fixed.
4. Press and hold side button one for 2 seconds to be taken to the LCD Display test mode.
3.3.3 LCD Display Test Mode
1. Press any button to test the LCD display, press button until the display are fixed. Then,
press and hold the first side button until the screen change.
2. Upon key
press, the housing shall display a White screen with 2 pixels wide of a black
border inset from the edge by 2 pixels and the text "Display Test Mode" in black.
3. Upon key
press, the housing shall display a Black screen with 2 pixels wide of a White
boarder inset from the edge by 2 pixels and the text "Display Test Mode" in White.
4. Upon key
press, the housing shall display a full screen in Red.
Table 3-2. Front Panel Access Test Mode Displays
Name of Display Description Appears
Service Mode The literal string indicates the radio has entered test mode. Always
Host Version The version of host firmware. Always
DSP Version The version of DSP firmware. Always
Model Number The radio’s model number as programmed in the codeplug. Always
MSN The radio’s serial number as programmed in the codeplug. Always
FLASHCODE The FLASH codes as programmed in the codeplug. Always
RF Band The radio’s band. Always
NOTE
The radio stops at each display for 2 seconds before moving to the next information display.
If the information cannot fit into 1 line, the radio display scrolls automatically character by
character after 1 second to view the whole information. If the Left Navigation Key (
) is
pressed before the last information display, the radio shall suspend the information display
until the user presses Right Navigation Key (
) to resume the information display. The
radio beeps for each button press. After the last display, RF Test Mode will be displayed.
