Disassembly/Reassembly Procedures Disassembling and Reassembling the Radio — General 5-5
5.5 Disassembling and Reassembling the Radio — General
When disassembling and reassembling the radio, it is important to pay particular attention to the
snaps and tabs, and how parts align with each other.
The following tools are required for disassembling the radio:
• TORX™ T4 and 6IP TORX Plus screwdriver
• Chassis and Knob Opener (TL000015A01)
The following item and tools are required for reassembling the radio:
• Grease (1185937A01)
• TORX™ T4 and 6IP TORX Plus screwdriver
• Vacuum Pump Kit (NLN9839) - Radio Immersibility Test
• Pressure Pump Kit (NTN4265) - Radio Immersibility Test
• Connector Fitting (5871134M01) - Radio Immersibility Test
• Fitting Seal (3271133M01) - Radio Immersibility Test
• Seal Port (3286058L01)
• Label Ventilation (5478220A01)
If a unit requires further testing or service than is customarily performed at the basic level, please
send the radio to a Motorola Service Center listed in Appendix B.
To assure the safety and regulatory compliance of the XPR 7000 Series, the
radio must be repaired only at Motorola service facilities. Please call Motorola
at 800-422-4210 for the address and contact information of your nearest
service center
