Motorola XPR 7550e User Manual

Limited Level 3 Servicing: Component and Parts list C-3
Table C-1 Component Parts List
No. Circuit Ref Motorola Part Num. Description
1 SW4044 4086470Z01 SPST Tact Switch
2 M0800
E0800
0987378K01
CN000794A01
SM Coaxial Connector
Female
3 S4010 40012023001 Frequency Switch
4 S4030 1875103C04 Volume Rotary On/Off
Switch
5 M4020 09012098002 Battery Contact
Connector
6 F4020 6515076H01 Fuse Fast Blow 3A 24V

Motorola XPR 7550e Specifications

General

Channel Capacity	1000 channels
IP Rating	IP68
Power Output	VHF: 1-5W, UHF: 1-4W
Digital Protocol	DMR
Bluetooth	Yes
GPS	Yes
Frequency Range	VHF: 136-174 MHz
Display	Full color 5-line display
Dimensions	5.1 x 2.2 x 1.4 in (130 x 55 x 36 mm)
