3-8 Transceiver Performance Testing Display Model Test Mode
* See Table 3-4
FSK Error DMR Mode. FSK Error TEST MODE,
Digital Mode,
transmit with
O153 test
pattern
Key up radio with
O513 test pattern
modulation using
Tuner
Not Exceed 5%
Magnitude
Error
DMR Mode. Magnitude
error
As above As above Not Exceed 1%
Symbol
Deviation
DMR Mode. Symbol
Deviation
As above As above Symbol Deviation
should be within
648Hz +/- 10% and
1944Hz +/- 10%
Transmitter
BER
DMR Mode As above As above Transmitter BER
should be 0%
Table 3-5. Transmitter Performance Checks (Continued)
Test Name
Communications
Analyzer
Radio Test Set Comments
