8 Settings via the MICT
44 Rev. 08/2018
Symbol Menu Function
File -> Print To PDF File
Prints the configuration to a PDF file.
File -> Print Preview
Opens a print preview of the configuration.
File -> Quit
Exits the MICT.
Device -> Connect
Connects to the device.
Device -> Disconnect
Cuts the connection to the device.
Device -> Download to
device
Downloads configuration data from the PC to the
device. This function can only be executed in manual
mode.
Device-> Upload from
device
Uploads configuration data from the device to the PC.
Device -> Runtime data
Opens the window Runtime Data. Refer to the section
Runtime Data on page 63.
Device -> Log
Opens the window Log (Advanced Service only). Refer
to the section Log on page 71.
Device -> Select Mode
Opens the window Select operation mode in which you
can select the operation mode. The following modes
are possible: Manual operation mode, Automatic
operation mode or Switch controls operation mode.
Device -> Manual
Adjustment
Opens a window in which you can manually adjust the
opening angle.
Device -> Open Position
Completely opens the throttle or the gas supply for the
gas mixer in manual mode.
Device -> Close Position
Completely closes the throttle or the gas supply for the
gas mixer in manual mode.
Device -> Position 1
In manual mode, drives to the position 1 defined in the
configuration by a percentage.
Device -> Position 2
In manual operation, drives to the position 2 defined in
the configuration by a percentage.
